Building Messages in Blend for Visual Studio

The other day Martin Zikmond tweeted about a messaging sample app he’d built using the Uno Platform, allowing the same app to run on iOS, Android, Windows, MacOS and Web. Whilst the concept was simple enough, the point was that there was almost no platform specific code and yet the app works and looks virtually … Continue reading “Building Messages in Blend for Visual Studio”

The other day Martin Zikmond tweeted about a messaging sample app he’d built using the Uno Platform, allowing the same app to run on iOS, Android, Windows, MacOS and Web. Whilst the concept was simple enough, the point was that there was almost no platform specific code and yet the app works and looks virtually the same on every platform.

Following my previous post where I did a walk through of some of the Blend for Visual Studio features I use, I thought I’d take the challenge to see how much of Martin’s app I could build using the designer in Blend. The good news is that you can get a long way; The bad news is that there are some features, such as ThemeResources, that seem to cause some issues with the designer – we’ll see this towards the end of the post.

New Project

Ok, so this is pretty self explanatory but Blend has a similar New Project experience to what you see in Visual Studio. Start by searching for the type of project you want to build. So that the designer works, we’re going to select a Blank App (Universal Windows). Once we’ve completed the design work we can copy the files across into our Uno project

Note: At the moment there’s no support for Shared Projects, which the default Uno solution is setup to use. If you follow my post on using multi-targeting with Uno you can use the designer if you load the Windows solution filter.

Give your project a name and location you want it saved.

At this point I typically make sure the application runs and that I’ve upgraded various NuGet packages. Next I’m going to copy in a bunch of the code files from Martin’s project that is available on GitHub. This includes the ViewModels, the SampleData and a couple of Assets.

In the code behind for the MainPage (MainPage.xaml.cs) I’ve added a ViewModel property that returns an instance of the MainViewModel. This will be used to provide both runtime and design time data.

Now let’s get to the designer. From the Assets tool window, search for “split” and drag the SplitView onto the design surface. The SplitView has a Pane, the collapsable panel that shows/hides when you tab the burger menu, and a main Content area. In Martin’s app the list of conversations is in the Pane, whilst the Messages for the selected conversation appear in the Content area.

I wanted to reuse the same color resources that Martin has, so I copied the contents of the App.xaml across to my project – It would be awesome if Microsoft could add back support for managing project resources, which was previously a feature of Blend but got lost in the update to the designer a couple of years ago.

Back to the designer and focus on the SplitView. From the Properties tool window locate the PaneBackground property. Select the Color Resources tab (yeh, Editor and Color Resources are a tab, not that it’s very obvious) and select the NavPaneBackgroundColor (this comes from the resources we added to App.xaml). Whilst we’re here, set the BackgroundSource property to HostBackdrop and TintOpacity to 50%. Check out the docs on Acrylic material for more information on using Windows specific brushes. This is one point where Martin has provided a different background for Windows versus the other platforms – check out the source code to see how he’s done this using platform namespaces.

When you launch the app on Windows you can see the effect of setting the Acrylic background on the pane of the splitview (left side of this image).

Next we’re going to set the Padding on the Grid located inside the Pane, which will inset the list of conversations away from the edge. Rather than just setting the Padding, which can be done using the Properties tool window, I’m going to convert this into a reusable resource. Click the square to the right of the property to display the context menu, then select Convert to New Resource.

Give the resource a name and specify where you want the resource to be saved.

In this case I’m going to go ahead and create a new Resource dictionary by clicking the New… button. Since we’ll use this resource dictionary for styles, templates and other resources, I’ve named it accordingly. When you click the Add button, not only does this resource dictionary get added to your project, it is also wired up as a merge dictionary in App.xaml.

Next we’re going to add a ListView to the Pane to display the list of conversations. Again from the Assets window, drag the ListView across onto the Pane in the designer.

Unfortunately there’s no designer support for working with x:Bind. However, you will get intellisense in the XAML editor to let you know what properties are available for binding to.

Despite setting the ItemsSource property, the ListView still remains empty on the designer – as I mentioned, no designer support for x:Bind. However, with the recently introduced design time data everywhere support that’s been added, you can take advantage of regular data binding at design time.

Firstly, we’ll add an instance of the MainViewModel as design time resource. Note that this is the same as adding normal resources, just with the “d:” prefix. However, be aware that setting attributes at design time will override any runtime values whilst in the designer. This normally isn’t an issue but when specifying resources, it will only pick up the design time resources, rather than attempting to combine the resource dictionaries.

<Grid>
    <d:Grid.Resources>
        <MainViewModel x:Key="DesignViewModel" />
    </d:Grid.Resources>

Note that the XAML editor is able to assist with applying namespaces etc. After adding the MainViewModel resource I get a prompt helping me to setup and use the namespace.

Next, set the ItemsSource property on the ListView, again using the design time prefix (i.e. d:ItemsSource=”{Binding Conversations}” ). Now we should start to see items appear in the ListView.

Let’s go ahead and create a data template for determining how each item will appear. Right-click on the ListView and select Edit Additional Templates, Edit Generated Items (ItemTemplate), followed by Create Empty. Give the DataTemplate a name and specify where you want to save it.

Rather than going through each element in the item template, I’m going to add the DataTemplate from Martin’s code. However, even after adding this data template, there’s no items appearing in the ListView. Again, this is because there’s no designer support for x:Bind. Luckily we can do the same trick, this time for each property we want to data bind. in this example we’re using the design time data binding for the Text property on the TextBlock

Ok, so now we’re starting to look good.

However, notice how the time is appearing at different positions for each item in the list. This is because the list item isn’t spanning the full width of the ListView. I’ve never understood why this is the default behaviour but it dates back as long as I can remember. Luckily there’s an easy fix, which is to set the HorizontalContentAlignment on the ListView to Stretch. However, this needs to be done on the ItemContainerStyle for the ListView. Right-click on the ListView, Edit Additional Templates and then this time select Edit Generated Item Container (ItemContainerStyle), followed by Create Empty.

Give the template a name and location for saving.

From the Properties tool window, search for “horizon” and change the HorizontalContentAlignment to Stretch (far right icon).

Now, the list of conversations is looking much better.

In the main Content area, lets start by creating three rows to host the header, messages and input TextBox. Using the mouse, you can draw the grid rows, and then use the designer to define the height for the rows. The first and third row should both be set to Auto, with the second row set to *.

Let’s add the input TextBox at the bottom of the screen. Click on the chevrons on the left edge of the design to expand out the Assets flyout. Search for textbox and double-click on the TextBox to add it to the designer.

Next, right-click on the newly created TextBox and select Layout, Reset All.

Depending on where the TextBox was added, you’ll probably have to set the Grid.Row to 2 in order for it to appear in the third row. Whilst in the Properties tool window, let’s set the CornerRadius to 12 and the Margin to 20 – again, I would typically extract these to resources so they can be reused across the app (similar to CSS classes if you’re more familiar with styling for the web).

At this point I’m going to grab the rest of the XAML for the Content area from Martin’s source code, rather than walking you through adding each of the controls. There was one exception to this – in Martin’s code he has used an ItemTemplateSelector to switch between two different item templates based on whether the message is from the current user or not. I’m going to take a different approach, so I’ve replaced the ItemTemplateSelector with just a single ItemTemplate. The resulting messages list looks like the following, where it’s no longer possible to distinguish who sent which message.

To fix this issue we’re going to use converters that take a bool value and determine what value to return. The first converter returns a HorizontalAlignment, either Left or Right, depending on the input value. I’ve set it to return Stretch if the input value isn’t a bool, effectively making it the default value.

Next we’re going to make use of this converter in the item template. Here we’ve selected the Border element and are about to click the Create Data Binding menu item.

In the Create Data Binding window, we select the IsFrom property, and then at the bottom of the window, select the BoolHorizontalAlignmentConverter.

If you run the app at this point you’ll see that the messages are aligned left and right according to who sent the message but there’s no difference in style. We can do the same process but this time for setting the Style of different elements in the template; this time using a BoolStyleConverter.

The difference with the BoolStyleConverter is that it needs a TrueStyle and FalseStyle to be defined. For example for the Border we can create two styles and then an instance of the BoolStyleConverter.

And the same for the TextBlock style

And then we apply these to the item template.

And voila, we have a similar layout to what Martin had

Ok, so just in conclusion there’s a couple of points:

  • Firstly, in the style for the Border and TextBlock it’s referencing a ThemeResource to set color. This is important so that you get support for light/dark mode. However, it also seems to break the designer support, resulting in no messages appearing on the screen. I think the resolution might be that the Styles themselves have to be defined as ThemeResources.
  • Secondly, you might be asking why I chose to use converters instead of an ItemTemplateSelector. The answer is that there isn’t any right or wrong answer, I just wanted to demonstrate a different way to appear the problem. In some cases the ItemTemplateSelector is preferred, particularly if there are massive differences between the templates. In this case, I would probably go with converters because you have a single ItemTemplate, so any changes you make will affect both From and To messages, without you having to remember to update both templates.

Hopefully you’ve seen how you can take advantage of Blend for Visual Studio to start building cross-platform experiences; start with Windows (UWP) and apply it to iOS, Android, MacOS and Web using the Uno Platform

Windows (UWP) Designer in Visual Studio and Blend for Visual Studio

If you’ve been looking at the release notes for the Visual Studio previews, you’ll have noted that there’s some work being done on the XAML designer that now supports both WPF and UWP. I figured I would take this opportunity to go through and document some of the features that I use and some of … Continue reading “Windows (UWP) Designer in Visual Studio and Blend for Visual Studio”

If you’ve been looking at the release notes for the Visual Studio previews, you’ll have noted that there’s some work being done on the XAML designer that now supports both WPF and UWP. I figured I would take this opportunity to go through and document some of the features that I use and some of the new features that have appeared in the previews. Note that this isn’t an exhaustive list by any means – would love feedback on what other features you use and what you think is missing in the designer.

One of the reasons that the designer experience in Visual Studio and Blend is so relevant is that you can take the design you’ve done for your Windows app and port it across to iOS, Android, MacOS and even the web (using Web Assembly). All these platforms are available via the Uno platform – If you’re new to the Uno Platform, head over to https://platform.uno/ and get started with building cross-platform mobile, desktop and Web applications.

New Project

Ok, so let’s start by creating ourselves a new Windows (UWP) project based on the Blank App (Universal Windows) template.

As usual, give the project a name to get started – you’ll be prompted to pick which target and minimum versions of Windows you want but for the purpose of this post I just went with the defaults.

Visual Studio Designer

Once created, depending on your setup of Visual Studio, you’ll probably have the MainPage.xaml already open. If not, find MainPage.xaml in the Solution Explorer tool window and double-click it to open it. Here you can see that I have the Toolbox on the left of the design surface and the Properties window, above the Solution Explorer, on the right side. I find this layout works well for working with the designer but you can easily customise the layout of the tool windows to suit how you work.

Design in Blend

We’re actually going to switch across to Blend for Visual Studio for the rest of this post. I prefer to do any designer work in Blend because I prefer to have the tool windows in a different position when doing design work, than when writing code. Switching between Visual Studio and Blend also gives me a mental switch to go between designer mode (well at least “layout-oriented work” mode, since I’m clearly not a designer) and developer mode.

It’s worth noting that the designer experience in Visual Studio and Blend is very similar – Microsoft made the decision years ago to build a consistent experience with the majority of functionality now available in both tools. Blend still retains a number of designer oriented features, such as creating visual states and animations with storyboards, that haven’t been exposed in the Visual Studio designer.

You can easily switch to Blend by right-clicking on the project or a XAML file in Solution Explorer and selecting Design in Blend.

As you can see the tool windows are labeled slightly differently in Blend and have a different default position. Again, feel free to reposition them to suit how you work.

Zoom

If you look at the main design surface, you’ll note that the initial position of the MainPage is very small. Working at this zoom level will be quite hard as each of the elements will be small and hard to manipulate.

In the bottom left corner of the design surface there’s a series of icon buttons and a dropdown. Expanding the dropdown allows you to select from a number of predefined zoom levels.

Alternatively you can select Fit all, or Fit selection, in order to bring the whole page into view.

The other way that you can control the positioning of the design area is using the mouse:

  • Scroll up/down – Two-finger drag on touch pad, or scroll wheel on mouse
  • Scroll left/right – Hold Shift + Two-finger drag on touch pad, or scroll wheel on mouse
  • Zoom in/out – Hold Ctrl + Two-finger drag on touch pad, or scroll wheel on mouse

Adding Controls with Assets Tool Window

Let’s start to add some controls to the page. We’ll use the Assets tool window to locate the TextBlock control using the search function.

If I just click and drag the TextBlock onto the design surface, Blend will add the control where I drop it.

Objects and Timeline Tool Window

If we take a look at the XAML you’ll note that a very arbitrary margin has been set on the TextBlock

Layout – Reset All

Right-click on the TextBlock in the Objects and Timelines tool window and select Reset All from the Layout menu.

Now the TextBlock has been reposition to take up the whole page.

However because text flows from the top-left, the word TextBlock is in the top left corner of the page.

Edit Style – Apply Resource

Next, let’s increase the size of the text. Instead of manually setting FontSize, we’re going to make use of one of the existing TextBlock styles. Right-click on the TextBlock again in the Objects and Timeline window and select Edit Style, Apply Resource and then we’ll select HeaderTextBockStyle. You can read more about predefined styles and the use of typography here.

This gives our TextBlock a nice size, without hard coding font sizes and styles randomly throughout the application.

Design Surface

Up to now I haven’t given you much context for this app – we’re going to build a simple interface that shows a list of contacts. The TextBlock we’ve added so far will act as a header/title for the page, and then beneath it we’ll need a ListView showing the list of our contacts.

Drawing Grid Rows

Before we can add the ListView, let’s create two rows in the Grid that the TextBlock is sitting in. Select the Grid in the Objects and Timelines window and then on the design surface, if you move the mouse cursor near the edge of the page, you’ll see the cursor change to one that’s got a small plus sign on it. Clicking at this position will add a row to the Grid.

Once added, you can then adjust the sizing of the row. In this scenario we’re going to change the row from 33* to being Auto, which will mean the row will be sized based on the height of the TextBlock.

Reset Grid.RowSpan in Properties Tool Window

One thing you may notice is that after adjusting the row size, the row seems to disappear. This is because in creating the row, Blend decided that the TextBlock was going to span both rows. To fix this, we can change the RowSpan on the TextBlock from 2 to 1 using the Properties tool window.

In this case, we’re going to select the Reset option, rather than setting it explicitly to 1. This will mean one fewer attributes in XAML that needs to be parsed.

Assets Button

Next up, we’re going to add the ListView to the second row. This time, instead of going all the way to the Assets tool window, we’re going to use the dropdown from the chevrons on the top left of the designer. This allows us to easily search and add controls, without having to open the tool windows – when doing a lot of design work I will often hide the tool windows (or even detach them and put them on a different monitor), so not having to open the tool windows to find a control is quite handy.

Runtime Toolbar

After dragging the ListView onto the page and making sure it’s sitting in the second row, I’m going to run the application to see what it looks like. Note that despite me not doing anything, the color of the title bar has aligned with my Windows theme (and yes, it’s pink because I’m using the setting where the theme is derived off the background I have set, which in turn is changed daily using the Dynamic Theme app).

Hot Reload

You’ll also note at the top of the window there is a toolbar that’s been added whilst I’m debugging the application. This toolbar has been available for a while but the Hot Reload indicator is a new addition. Hot Reload allows you to make changes to your XAML and for it to immediately take effect on the page when you save the XAML file (Hot Reload can be configured via Options off the Tools menu).

Display Layout Adorners

I’m going to toggle the Display Layout Adorners button (immediately adjacent to the left of the Hot Reload green tick).

Select Element

Next I’m going to click on the Select Element button (second in from the left) and click on the open space immediately below the TextBlock. As you can see, this highlights the whole area in a light blue (the layout adorner) which is the ListView.

Go to Live Visual Tree

Next I can click on the Go to Live Visual Tree button (first from the left) which will switch back to Visual Studio with the focus being set on the appropriate node in the Live Visual Tree.

XAML Editor

You’ll also note that the corresponding code in the XAML editor has been selected. As I start to type in the XAML editor I get intellisense showing me what options I have.

I’ve gone ahead and set a simple data template for the ListView which will determine what’s displayed for each item in the list. In this case it’s just going to print the word “Hi” for each item.

XAML Highlighting

Note that as I move the cursor around the XAML editor, the matching pairs of XML tags are highlighted, making it easy to see start and end of the blocks of XAML.

DataContext for Data Binding

Currently, despite setting a data template, the ListView isn’t going to show any items because I haven’t connected it to any data. To allow me to continue to layout elements on the page I’ve created some mock, or fake, data.

public class FakeData
{
    public Contact[] Contacts { get; } = new[]
    {
        new Contact(){Name="Bob Jones",PhoneNumber="+1 442 002 3234", Photo="ms-appx:///Assets/Photos/p0.jpg"},
        new Contact(){Name="Jessica Phelps",PhoneNumber="+1 394 234 1235", Photo="ms-appx:///Assets/Photos/p1.jpg"},
        new Contact(){Name="Andrew Jenkins",PhoneNumber="+1 232 282 29321", Photo="ms-appx:///Assets/Photos/p2.jpg"},
        new Contact(){Name="Francis Davis",PhoneNumber="+1 92329 2923 923", Photo="ms-appx:///Assets/Photos/p3.jpg"},
        new Contact(){Name="Xavier Smith",PhoneNumber="+1 93483 3923423", Photo="ms-appx:///Assets/Photos/p4.jpg"},
        new Contact(){Name="Kevin Chow",PhoneNumber="+1 343 994 39342", Photo="ms-appx:///Assets/Photos/p5.jpg"},
        new Contact(){Name="Phil Stevenson",PhoneNumber="+1 885 367 44432", Photo="ms-appx:///Assets/Photos/p6.jpg"},
        new Contact(){Name="Heath Sales",PhoneNumber="+1 903 912 9392", Photo="ms-appx:///Assets/Photos/p7.jpg"},
        new Contact(){Name="Sarah Wright",PhoneNumber="+1 347 399 499234", Photo="ms-appx:///Assets/Photos/p8.jpg"},
        new Contact(){Name="Geoff Sans",PhoneNumber="+1 834 1232 01923", Photo="ms-appx:///Assets/Photos/p9.jpg"}
    };
}

I can go ahead and create an instance of the FakeData class as a Resource on the Page. This instance is then set as the DataContext for the root Grid element on the page (and subsequently the DataContext for all elements on the page).

The ItemsSource on the ListView is then data bound to the Contacts property on the FakeData instance. The running application updates immediately to show a list of “Hi” down the screen.

Hide the Runtime Toolbar

As we start to design the page, the toolbar at the top can often get in the way. If you click on the chevron on the right side of the toolbar, the first click will reduce the size of the Hot Reload indicator (removing the words Hot Reload). The second click will minimise the toolbar completely.

Let’s amend the data template for the list, this time data binding to the Name property.

The ListView is immediately looking better, showing the names of the people in the Contacts list.

Edit ListView Item Template

If your working in the designer there are a number of ways you can make changes to the data template for the list. In this example we’re using the dropdown at the top left corner of the design area. Clicking the down button, followed by Edit Additional Template, then Edit Current, then Edit Generated Items (ItemTemplate).

Objects and Timeline – Group Into

You’ll notice that the Objects and Timeline window updates to show the tree from the perspective of the data template. Right-clicking on the TextBlock I can select Group Into, followed by StackPanel, to wrap the TextBlock in a StackPanel.

TextBlock Button

Next, I can add a TextBlock to the newly created StackPanel but simply double-clicking the TextBlock button on the left of the design area.

XAML Suggested Actions

One of the newest additions to the designer is the XAML Suggested Actions. Anyone who’s worked in Word or Excel is familiar with the suggested actions toolbar that often appears to try to make more of the tools are accessible when you need them. in this case we can click on the lightbulb button to display an in-situ property editor.

In this case we’re going to click through to Create Data Binding.

Create Data Binding

From the Create Data Binding window we can traverse down to the PhoneNumber property on the Contact object.

Note that there’s a minor bug at this point because the data binding that’s created isn’t 100% accurate. Instead of data binding to the PhoneNumber property (eg {Binding PhontNumber}) the generated binding is with Contacts.PhoneNumber. Simply removing the “Contacts.” prefix is enough to get it to work.

Edit ColumnDefinitions

I’m going to follow a similar approach to before – select the StackPanel and group into a Grid. From the Properties tool window find the ColumnDefinitions.

Click the … to open the Collection Editor for the ColumnDefinitions. Here we’re going to limit the first column to 50 pixels and then leave the second column as *.

I’ve update the data template with the profile picture as an image. Simply add an Image control and follow the same process as before to setup data binding to the Photo property on the Contact.

WinUI – ProfilePicture Control

To improve the layout of the contacts I’m going to use the ProfilePicture control, which will ensure all the images are the same size.. Instead of using the built in control, I’m going to grab the ProfilePicture control from the WinUI toolkit. Using the nuget package manager, select the Microsoft.UI.Xaml package and install it.

Once you’ve added the nuget package, make sure you don’t ignore the readme file that’s displayed to remind you to include the appropriate runtime values.

We’re almost there, we just need to add the PersonProfile, which we can do by discovering it in the Assets window (even though its from a third party)

And so now we have all our contacts appearing.

Final Design

After applying some minor tweaks to the layout of the data set, we can have a nicer looking sample app.

Before I copied the final code to this post, I just wanted to format the XAML. From the Options window, you can configure how you want your XAML files to appear.

Then, once you have the formatting options the way you want them, you can invoke Format Document from the various places around the design surface.

Final XAML

And here’s the final source code

<Page xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:local="using:WindowsDesigner"
      xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
      xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
      xmlns:Custom="using:Microsoft.UI.Xaml.Controls"
      x:Class="WindowsDesigner.MainPage"
      mc:Ignorable="d">
    <Page.Resources>
        <local:FakeData x:Key="DesignTimeData" />
    </Page.Resources>

    <Page.Background>
        <ThemeResource ResourceKey="ApplicationPageBackgroundThemeBrush" />
    </Page.Background>

    <Grid DataContext="{StaticResource DesignTimeData}">
        <Grid.RowDefinitions>
            <RowDefinition Height="Auto" />
            <RowDefinition />
        </Grid.RowDefinitions>
        <TextBlock Margin="16"
                   Text="Contacts"
                   TextWrapping="Wrap"
                   Style="{StaticResource HeaderTextBlockStyle}" />
        <ListView Grid.Row="1"
                  ItemsSource="{Binding Contacts}">
            <ListView.ItemTemplate>
                <DataTemplate>
                    <Grid Margin="8">
                        <Grid.ColumnDefinitions>
                            <ColumnDefinition Width="50" />
                            <ColumnDefinition />
                        </Grid.ColumnDefinitions>
                        <StackPanel Orientation="Vertical"
                                    Grid.Column="1"
                                    Margin="8"
                                    HorizontalAlignment="Center">
                            <TextBlock Text="{Binding Name}"
                                       Style="{StaticResource BaseTextBlockStyle}" />
                            <TextBlock Text="{Binding PhoneNumber}"
                                       Style="{StaticResource BodyTextBlockStyle}" />
                        </StackPanel>
                        <Custom:PersonPicture Width="50"
                                              Height="50"
                                              ProfilePicture="{Binding Photo}" />
                    </Grid>
                </DataTemplate>
            </ListView.ItemTemplate>
        </ListView>
    </Grid>
</Page>

And that’s it – hopefully you’ve learnt a bit more about how to use the XAML editor and the new designer features.

Consuming REST API with Swagger / OpenAPI in Xamarin and Uno Applications

I still recall the simplicity of standing up a SOAP service and adding a service reference via Visual Studio by simply entering the url to the WSDL – this scenario just worked…. until we moved on. There was a rapid progression away from the overly prescriptive XML based world of SOAP to REST based APIs. … Continue reading “Consuming REST API with Swagger / OpenAPI in Xamarin and Uno Applications”

I still recall the simplicity of standing up a SOAP service and adding a service reference via Visual Studio by simply entering the url to the WSDL – this scenario just worked…. until we moved on. There was a rapid progression away from the overly prescriptive XML based world of SOAP to REST based APIs. This was all well and good but there was no longer a standard approach to documenting these APIS. Enter Swagger, and subsequently OpenAPI, as a way to document REST based APIs. Rather than spend time in this post detailing how you can add some Swagger to your web api (look here if you’re interested), I’m going to focus on consuming a REST based API by first importing its Swagger and using that to generate the code for accessing the API.

One of the most important points to note about this process, is that we’ll be working with a .NET Standard 2.0 class library. This means that the same library can be used across any application you might want to build, whether it be a console application, or a Xamarin.Forms app, or a Uno app (go to https://platform.uno/ to learn more about the Uno Platform).

In fact, to illustrate this point, I have a solution which has both a Uno and a Xamarin.Forms application in it. The solution also has a Data project (just a regular .NET Standard 2.0 library), which is where we’ll be importing the Swagger document. The Data project is referenced by each of the head projects for both Xamarin.Forms and Uno.

The REST service that we’re going to call is one that I setup as part of generating the OCS files for Build 2020 (more details here). The swagger documentation can be found at https://build2020.builttoroam.com/swagger/index.html, which is just a pretty version of the actual Swagger/OpenAPI document that’s located at https://build2020.builttoroam.com/swagger/v1/swagger.json

The process for referencing a REST API that has a Swagger or OpenAPI is now one of the global tools that ships with the dotnet cli. High level documentation for the OpenAPI tool can be found on the Microsoft docs website. We’ll step through the process here as it’s relatively simple.

To start with, we need to make sure that the openapi tool has been installed. This can be done by running the following at a command prompt:

dotnet tool install -g Microsoft.dotnet-openapi

Next, navigate to the folder of the project you want to reference the swagger document and call the openapi command, along with the “add url” parameter (and of course the url of the swagger document).

dotnet openapi add url https://build2020.builttoroam.com/swagger/v1/swagger.json

Returning to Visual Studio we can see that a file, swagger.json, has been added to the Data project.

We’ll add a small snippet of code to call one of the REST APIs.

var client = new swaggerClient("https://build2020.builttoroam.com", new System.Net.Http.HttpClient());
var sessions = await client.SessionsAsync();
System.Diagnostics.Debug.WriteLine(sessions.Count);

This is all well and good but what happens if you want to customize the generated code….oh wait, what….generated code… I forgot to mention, as part of building the Data library, the swagger.json document that was added to your project is converted into a set of classes that make invoking the REST APIs super easy (as you saw above in the code example).

If you press F12 when the cursor is located in swaggerClient class name (or just right-click on the swaggerClient class and select Go To Definition) you’ll be taken to the generated swaggerClient.cs file (in the obj folder). Don’t make changes directly to this file as they will get overwritten the next time you build the Data project.

As I was about to say, there are a couple of ways you can customize the generated code. The first way is to adjust the code generation itself. You can do this by supplying options that configure the way the code generation is done. When the “dotnet openapi” command was invoked earlier, in addition to adding the swagger.json file to the project, an entry was added to the csproj file.

<OpenApiReference Include="swagger.json" SourceUrl="https://build2020.builttoroam.com/swagger/v1/swagger.json" />

The OpenApiReference element in the csproj invokes the code generation during the build process by calling out to the popular NSwag command line tool. As such the options that can be used are the same as for the Nswag tool (A full list of options can be found in the NSwag source code here). For example, let’s ensure an interface is generated for the swaggerClient class, we can set the GenerateClientInterfaces property to true.

<Project Sdk="Microsoft.NET.Sdk">
	<PropertyGroup>
		<TargetFramework>netstandard2.0</TargetFramework>
	</PropertyGroup>
	<ItemGroup>
		<PackageReference Include="Newtonsoft.Json" Version="12.0.2" />
		<PackageReference Include="NSwag.ApiDescription.Client" Version="13.0.5" />
	</ItemGroup>
	<ItemGroup>
		<OpenApiReference Include="swagger.json" SourceUrl="https://build2020.builttoroam.com/swagger/v1/swagger.json">
			<Options>/GenerateClientInterfaces:true</Options>
		</OpenApiReference>
	</ItemGroup>
</Project>

The other way we can extend the swaggerClient class is by adding the implementation of one or more of the partial methods that has been created. Again, if you go to definition on the swaggerClient class, you can see these partial method declarations.

To implement these partial methods, simply add a partial class called swaggerClient to the project, and add the method you want to implement. For example, adding the PrepareRequest method, you can log out the actual url of each API call.

And there you have it, a super simple way to reference a REST API from a .NET Standard library, which can then be used by your Xamarin.Forms, Uno or even a console app.

Big shout out to Rico Suter for the amazing work he’s done with the NSwag library

iOS Hot Restart, Multi-Targeting and Solution Template for Cross-Platform Applications with Uno

In my last couple of posts I covered setting up multi-targeting and improving the developer experience with multi-targeting. This was in the context of an application that supported iOS (Xamarin iOS), Android (Xamarin Android) and Windows (UWP). In this post we’re going to look at a template for Uno cross-platform applications. If you’re new to … Continue reading “iOS Hot Restart, Multi-Targeting and Solution Template for Cross-Platform Applications with Uno”

In my last couple of posts I covered setting up multi-targeting and improving the developer experience with multi-targeting. This was in the context of an application that supported iOS (Xamarin iOS), Android (Xamarin Android) and Windows (UWP). In this post we’re going to look at a template for Uno cross-platform applications.

If you’re new to the Uno Platform, head over to https://platform.uno/ and get started with building cross-platform mobile, desktop and Web applications.

The main points we’ll review are:

  • Creating a Uno application that targets iOS, Android, MacOS, Windows and Wasm (browsers/web).
  • Add class library, Core, for housing business logic (eg ViewModels)
  • Add class library, UI, for housing pages, controls etc
  • Add Hot Restart to the iOS head project
  • Add target framework switching and solution filters.
  • Refactoring project files to extract Uno references to make it easier to update references

If you want to jump straight to the final project/solution structure, then you can take a look at the final source code on the GitHub repository

Creating Your First Uno Application

For the purposes of this post we’re going to work with a new Uno application. However, there’s no reason why you can’t retrofit any, or all, of these steps to an existing project.

Start by searching for the Uno application template (If you don’t have these templates, then install them from the marketplace).

Give the application a name – We’ll use MultiTargetingWithUno.

Creating Uno Class Libaries

In this example, we’re going to create separate class libraries to house our pages and our ViewModels. But before we get on with creating them, we’re going to do a quick bit of tidying up.

Create PlatformHeads Solution Folder, and move all existing projects into PlatformHeads folder. This will group the head projects (i.e. the application projects that you can deploy and run) so that they don’t have other projects intermingled with them.

The next thing to do is to create two libraries: Core and UI. Search for Uno again but this time pick the Cross Platform Library option.

Next, give your library a name, and then repeat the process for both MultiTargetingWithUno.Core and MultiTargetingWithUno.UI libraries.

Delete the default Class1.cs file from both Core and UI projects, and make sure there is a reference from the UI project to Core.

Add reference to both UI and Core projects to the Shared project (so it gets added to each head project).

<?xml version="1.0" encoding="utf-8"?>
<Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">
    . . .
    <ItemGroup>
    <ProjectReference Include="..\..\MultiTargetingWithUno.Core\MultiTargetingWithUno.Core.csproj" />
    <ProjectReference Include="..\..\MultiTargetingWithUno.Core\MultiTargetingWithUno.UI.csproj" />
  </ItemGroup>
</Project>

MSBuild.Sdk.Extras

This step is primarily around refactoring the Core and UI projects to make them easier to maintain by relocating various properties so that both projects share the same declarations.

In both Core and UI project files, the sdk references is MSBuild.Sdk.Extras/2.0.54. Change this by removing the specific version number, i.e. 2.0.54. Instead of specifying the version of the package inline, we’re going to specify it in a global.json file located in the solution folder.

Inside the globa.json we just need to include the sdk and its corresponding version number.

{
    "msbuild-sdks": {
        "MSBuild.Sdk.Extras": "2.0.54"
    }
}

Your solution structure should look similar to the following.

Next we’re going to add a new solution item, libraries.targets. This is going to contain most of the properties that are in common across the Core and UI projects. This way if we need to adjust properties, we can do it in one place and have it applied to both libraries.

<Project>
	<PropertyGroup>
		<TargetFrameworks>netstandard2.0;xamarinios10;xamarinmac20;MonoAndroid90;monoandroid10.0;uap10.0.16299</TargetFrameworks>
		<!-- Ensures the .xr.xml files are generated in a proper layout folder -->
		<GenerateLibraryLayout>true</GenerateLibraryLayout>
	</PropertyGroup>
	<PropertyGroup Condition="'$(TargetFramework)'=='netstandard2.0'">
		<DefineConstants>$(DefineConstants);__WASM__</DefineConstants>
	</PropertyGroup>
	<ItemGroup Condition="'$(TargetFramework)'=='xamarinios10' or '$(TargetFramework)'=='MonoAndroid90' or '$(TargetFramework)'=='monoandroid10.0' or '$(TargetFramework)'=='netstandard2.0'">
		<PackageReference Include="Uno.UI" Version="2.4.0" />
	</ItemGroup>
	<ItemGroup>
		<Page Include="**\*.xaml" Exclude="bin\**\*.xaml;obj\**\*.xaml" />
		<Compile Update="**\*.xaml.cs">
			<DependentUpon>%(Filename)</DependentUpon>
		</Compile>
	</ItemGroup>
	<ItemGroup>
		<UpToDateCheckInput Include="**\*.xaml" Exclude="bin\**\*.xaml;obj\**\*.xaml" />
	</ItemGroup>
</Project>

Update the Core csproj file to remove everything inside the Project element, except the Import that references the newly created libraries.targets file.

<?xml version="1.0" encoding="utf-8"?>
<Project Sdk="MSBuild.Sdk.Extras">
	<Import Project="..\libraries.targets" />
</Project>

Repeat this for the UI csproj file. However, you need to keep the project reference to the Core project.

<?xml version="1.0" encoding="utf-8"?>
<Project Sdk="MSBuild.Sdk.Extras">
	<Import Project="..\libraries.targets" />
	<ItemGroup>
		<ProjectReference Include="..\MultiTargetingWithUno.Core\MultiTargetingWithUno.Core.csproj" />
	</ItemGroup>
</Project>

Target Framework Switching and Solution Filtering

As we did in my previous post, we’re going to update the Core and UI projects to allow for easy switching between active target framewrks.

We first need to add Directory.build.props to the solution folder. This is used to setup various project properties that can be used to conditionally set what target frameworks are defined.

<Project>
	<PropertyGroup>
		<IsWasmHeadProject>$(MSBuildProjectName.Contains('.Wasm'))</IsWasmHeadProject>
		<IsAndroidHeadProject>$(MSBuildProjectName.Contains('.Droid'))</IsAndroidHeadProject>
		<IsiOSHeadProject>$(MSBuildProjectName.Contains('.iOS'))</IsiOSHeadProject>
		<IsMacOSHeadProject>$(MSBuildProjectName.Contains('.macOS'))</IsMacOSHeadProject>
		<IsWindowsHeadProject>$(MSBuildProjectName.Contains('.UWP'))</IsWindowsHeadProject>
		<IsLibraryProject>!$(IsWasmHeadProject) and !$(IsAndroidHeadProject) and !$(IsiOSHeadProject) and !$(IsMacOSHeadProject) and !$(IsWindowsHeadProject)</IsLibraryProject>
	</PropertyGroup>

	<PropertyGroup>
		<IsWindows>$(TargetFramework.StartsWith('uap'))</IsWindows>
		<IsAndroid>$(TargetFramework.StartsWith('monoandroid'))</IsAndroid>
		<IsiOS>$(TargetFramework.StartsWith('xamarinios'))</IsiOS>
		<IsMac>$(TargetFramework.StartsWith('xamarinmac'))</IsMac>
		<IsWasm>$(TargetFramework.StartsWith('netstandard'))</IsWasm>
	</PropertyGroup>

	<PropertyGroup>
		<TargetsToBuildDeveloperOverride>All</TargetsToBuildDeveloperOverride>
	</PropertyGroup>

	<PropertyGroup Condition=" '$(Configuration)' == 'Debug' ">
		<TargetsToBuild>$(TargetsToBuildDeveloperOverride)</TargetsToBuild>
	</PropertyGroup>

	<PropertyGroup Condition=" '$(Configuration)' != 'Debug' ">
		<TargetsToBuild>All</TargetsToBuild>
	</PropertyGroup>
</Project>

Next, update the libraries.targets. The main changes are in bold, where the TargetsToBuild property is used to determine what target frameworks are defined.

<Project>
	<PropertyGroup Condition=" '$(TargetsToBuild)' == 'All' ">
		<TargetFrameworks>netstandard2.0;xamarinios10;xamarinmac20;monoandroid10.0;</TargetFrameworks>
		<TargetFrameworks Condition=" '$(OS)' == 'Windows_NT' ">uap10.0.16299;$(TargetFrameworks)</TargetFrameworks>
	</PropertyGroup>

	<PropertyGroup Condition=" '$(TargetsToBuild)' != 'All' ">
		<TargetFrameworks Condition=" '$(TargetsToBuild)' == 'Android' ">monoandroid10.0;</TargetFrameworks>
		<TargetFrameworks Condition=" '$(TargetsToBuild)' == 'Windows' ">uap10.0.16299</TargetFrameworks>
		<TargetFrameworks Condition=" '$(TargetsToBuild)' == 'iOS' ">xamarinios10</TargetFrameworks>
		<TargetFrameworks Condition=" '$(TargetsToBuild)' == 'Mac' ">xamarinmac20</TargetFrameworks>
		<TargetFrameworks Condition=" '$(TargetsToBuild)' == 'Wasm' ">netstandard2.0</TargetFrameworks>
	</PropertyGroup>

	<ItemGroup>
		<Compile Remove="**\*.netstandard.cs" Condition="'$(IsWASM)' != 'true'"/>
		<Compile Remove="**\*.droid.cs" Condition="'$(IsAndroid)' != 'true'"/>
		<Compile Remove="**\*.mac.cs" Condition="'$(IsMac)' != 'true'" />
		<Compile Remove="**\*.ios.cs" Condition="'$(IsiOS)' != 'true'"/>
		<Compile Remove="**\*.windows.cs" Condition="'$(IsWindows)' != 'true'" />
	</ItemGroup>

	<PropertyGroup>
		<GenerateLibraryLayout>true</GenerateLibraryLayout>
	</PropertyGroup>
	<PropertyGroup Condition="'$(TargetFramework)'=='netstandard2.0'">
		<DefineConstants>$(DefineConstants);__WASM__</DefineConstants>
	</PropertyGroup>
	<ItemGroup Condition="'$(TargetFramework)'=='xamarinios10' or '$(TargetFramework)'=='MonoAndroid90' or '$(TargetFramework)'=='monoandroid10.0' or '$(TargetFramework)'=='netstandard2.0'">
		<PackageReference Include="Uno.UI" Version="2.4.0" />
	</ItemGroup>
	<ItemGroup>
		<Page Include="**\*.xaml" Exclude="bin\**\*.xaml;obj\**\*.xaml" />
		<Compile Update="**\*.xaml.cs">
			<DependentUpon>%(Filename)</DependentUpon>
		</Compile>
	</ItemGroup>
	<ItemGroup>
		<UpToDateCheckInput Include="**\*.xaml" Exclude="bin\**\*.xaml;obj\**\*.xaml" />
	</ItemGroup>
</Project>

So that we can see what target framework was built, we’ll add the AppProperties.cs and each platform file (eg AppProperties.android.cs) that we created in the previous post.

In order to switch target frameworks, add the launch batch files and solution filters – see previous post.

MainPage and MainViewModel

Ok, so now we can get on to adding some functionality. We’ll start by creating a ViewModels folder in Core project and then adding a basic class, MainViewModel.

namespace MultiTargetingWithUno.Core.ViewModels
{
    public class MainViewModel
    {
        public string WelcomeText { get; } = "Hello World!";
    }
}

The MainPage already exists, but it’s currently in the Shared project. Move the MainPage to UI project. After moving the MainPage, make sure you double check the csproj file for the UI project – Visual Studio has a nasty habit of adding unnecessary elements to the csproj. In this case, you shouldn’t have any explicit entries for MainPage.xaml or MainPage.xml.cs, since they will both be added to the project by default with the correct build action.

Update MainPage to correct the namespace from MultiTargetingWithUno.MainPage to MultiTargetingWithUno.UI.MainPage. We’ll also update the Text attribute on the TextBlock to use x:Bind to show the welcome message from WelcomeText property on the the ViewModel that’s created in the code behind.

<Page
    x:Class="MultiTargetingWithUno.UI.MainPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
    xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
    mc:Ignorable="d">
    <StackPanel Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
        <TextBlock Text="{x:Bind ViewModel.WelcomeText}" Margin="20" FontSize="30" />
    </StackPanel>
</Page>

And the code behind which instantiates the MainViewModel.

using MultiTargetingWithUno.Core.ViewModels;

namespace MultiTargetingWithUno.UI
{
    public sealed partial class MainPage
    {
        public MainViewModel ViewModel { get; } = new MainViewModel();

        public MainPage()
        {
            InitializeComponent();
        }
    }
}

Update App.xaml.cs in the Shared project to reference the MainPage (you may need to rebuild the solution in order for the intellisense to kick in and help you add the necessary using statements)

Set Windows head project (ie MultiTargetingWithUno.UWP) as the startup project and attempt to build and run the application.

If you see a message in Output window such as “Project not selected to build for this solution configuration”, change the Solution Platform to either x86 or x64 (alternatively you can modify the configuration to include the UWP head project when AnyCPU is selected).

Sometimes building for the first time you may need to force a rebuild of Core, UI and then the UWP head project.

At the time of writing, if you’d followed the steps to this point you’ll actually get an error similar to “error CS0103: The name ‘InitializeComponent’ does not exist in the current context”.

This is because the Uno.UI package hasn’t been added to the Mac target framework. To fix this, change the Condition for ItemGroup in the UI csproj from “‘$(TargetFramework)’==’xamarinios10’ or ‘$(TargetFramework)’==’MonoAndroid90’ or ‘$(TargetFramework)’==’monoandroid10.0’ or ‘$(TargetFramework)’==’netstandard2.0′” to just “‘$(TargetFramework)’!=’uap10.0.16299′” eg.

<ItemGroup Condition="'$(TargetFramework)'!='uap10.0.16299'">
	<PackageReference Include="Uno.UI" Version="2.4.0" />
</ItemGroup>

And then, just when you thought we’d be done, you’ll also see another error, this time when you launch the UWP application:

System.AccessViolationException (0x80004003). Attempted to read or write protected memory. This is often an indication that other memory is corrupt.

This is a nasty error introduced by Microsoft at some point, preventing UWP applications from launching if there’s no pages defined in the application project. The solution is to add a dummy page to the UWP head project, call it “DoNotRemoveOrUsePage.xaml”.

Now you should be able to build and run the application but as you can see, there’s no indication of what platform we’re running on.

Let’s just update the WelcomeText on the MainViewModel to return platform information

public string WelcomeText { get; } = "Hello World! " + AppProperties.AppName;

That’s looking better – at this point you should be able to run the other platforms and see the welcome text vary with each platform.

Project File Refactor

In this section we’re going to do a bit of a tidy up of the Uno package references, extracting them out of the various project files so that they’re easier to manage in a central location.

Firstly we’ll add the logging packages to Directory.build.props, since they’ll be used by the Core, UI and all the head projects.

<ItemGroup>
	<PackageReference Include="Microsoft.Extensions.Logging.Console" Version="1.1.1" />
	<PackageReference Include="Microsoft.Extensions.Logging.Filter" Version="1.1.1" />
</ItemGroup>

Next, we’ll create a new file, uno.targets, in the solution folder. This will include the Uno.Core (which all projects will refernece), along with Imports for different platforms. This will seem quite messy, and to be honest it is, but the way this is structured is based on a limitation of the legacy project system used by UWP, iOS, Android and Mac. The legacy project system won’t process conditional ItemGroups. However, they do support conditional Import statements, such as those in the uno.targets.

<Project>
  <ItemGroup>
     <PackageReference Include="Uno.Core" Version="2.0.0" />
  </ItemGroup>

  <Import Project="uno.ui.targets"  Condition="'$(IsWindows)' != 'true' and '$(IsWindowsHeadProject)' != 'true'"/>

  <Import Project="uno.android.targets"  Condition="'$(IsAndroidHeadProject)' == 'true'"/>
  <Import Project="uno.wasm.targets"  Condition="'$(IsWasmHeadProject)' == 'true'"/>

  <Import Project="uno.debugging.targets"  Condition="'$(Configuration)' == 'Debug'"/>
</Project>

The uno.targets is imported into the Directory.build.props so that it gets added to each project in the solution.

<Import Project="uno.targets" />

Create the uno.ui.targets file which includes a reference to the Uno.UI package. As you can see from the uno.targets file, the Uno.UI package needs to be imported into every project other than the Windows or Windows head projects

<Project>
	<ItemGroup>
		<PackageReference Include="Uno.UI" Version="2.4.4"  />
	</ItemGroup>
</Project>

Next up is the uno.android.targets, which is used to add the Uno.UniversalimageLoader package to the Android head project.

<Project>
	<ItemGroup>
		<PackageReference Include="Uno.UniversalImageLoader" Version="1.9.32" />
	</ItemGroup>
</Project>

Then, the uno.wasm.targets includes the Bootstrap packages which are required by the Wasm head project:

<Project>
	<ItemGroup>
		<PackageReference Include="Uno.Wasm.Bootstrap" Version="1.2.0" />
		<PackageReference Include="Uno.Wasm.Bootstrap.DevServer" Version="1.2.0" />
	</ItemGroup>
</Project>

Lastly the uno.debugging.targets is only included for the Debug configuration.

<Project>
	<ItemGroup>
		<PackageReference Include="Uno.UI.RemoteControl" Version="2.4.4"  />
	</ItemGroup>
</Project>

With the uno.targets (and its nested imports) added to the Directory.build.props, we can go through an clean up any references to Uno packages throughout the various project files.

  • In libraries.targets, remove ItemGroup with Condition “‘$(TargetFramework)’!=’uap10.0.16299′” that includes a package reference for Uno.UI
  • Remove references to Uno from head projects: Uno.UI, Uno.UI.RemoteControl, Uno.UniversalImageLoader, Uno.Wasm.Bootstrap, Uno.Wasm.Bootstrap.DevServer, Microsoft.Extensions.Logging.Console and Microsoft.Extensions.Logging.Filter

The other piece of refactoring we’ll do is to add a Directory.build.targets file to the solution folder, which defines various helpful properties and constants. These are useful if you ever have to write conditional logic in your code, or tweak debug output etc.

<Project>
	<PropertyGroup Condition=" '$(Configuration)' == 'Debug' ">
		<DefineConstants>$(DefineConstants);TRACE;DEBUG</DefineConstants>
		<DebugType>full</DebugType>
		<DebugSymbols>true</DebugSymbols>
	</PropertyGroup>
	<PropertyGroup Condition="$(IsWASM)">
		<DefineConstants>$(DefineConstants);NETSTANDARD;PORTABLE;__WASM__</DefineConstants>
	</PropertyGroup>
	<PropertyGroup Condition="$(IsWindows)">
		<DefineConstants>$(DefineConstants);NETFX_CORE;XAML;WINDOWS;WINDOWS_UWP;UWP</DefineConstants>
		<TargetPlatformVersion>10.0.16299.0</TargetPlatformVersion>
		<TargetPlatformMinVersion>10.0.16299.0</TargetPlatformMinVersion>
	</PropertyGroup>
	<PropertyGroup Condition="$(IsiOS)">
		<DefineConstants>$(DefineConstants);MONO;UIKIT;COCOA;APPLE;IOS</DefineConstants>
	</PropertyGroup>
	<PropertyGroup Condition="$(IsMac)">
		<DefineConstants>$(DefineConstants);MONO;COCOA;APPLE;MAC</DefineConstants>
	</PropertyGroup>
	<PropertyGroup Condition="$(IsAndroid)">
		<DefineConstants>$(DefineConstants);MONO;ANDROID</DefineConstants>
		<MonoAndroidResourcePrefix>Resources</MonoAndroidResourcePrefix>
		<AndroidResgenClass>Resource</AndroidResgenClass>
		<AndroidResgenFile>Resources\Resource.designer.cs</AndroidResgenFile>
	</PropertyGroup>
</Project>

iOS Hot Restart

The last feature we’re going to add is support for iOS Hot Restart – the ability to run on an iOS device without needing a Mac! The Uno team blogged about this already but I’ll repeat it here to make things easier.

Add the following to main.cs – this will only be included in a debug build, so you don’t need to worry about it polluting your production code. Hot Restart works by pushing out a pre-built Xamarin.Forms application to the iOS device and then dynamically loading your application into it. This Uno doesn’t use Xamarin.Forms, this extra code is required to piggy-back on the process Microsoft has created for Hot Restart.

#if DEBUG
	public class HotRestartDelegate : Xamarin.Forms.Platform.iOS.FormsApplicationDelegate
	{
		public override bool FinishedLaunching(UIApplication uiApplication, NSDictionary launchOptions)
		{
			Windows.UI.Xaml.Application.Start(_ => new App());
			return base.FinishedLaunching(uiApplication, launchOptions);
		}
	}
#endif

Create uno.debugging.hotrestart.targets that references the Xamarin.Forms package.

<Project>
	<ItemGroup>
		<PackageReference Include="Xamarin.Forms" Version="4.6.0.800" />
	</ItemGroup>
</Project>

Update uno.debugging.targets to conditionally import the uno.debugging.hotrestart.targets for the iOS head project.

<Import Project="uno.debugging.hotrestart.targets" Condition=" '$(IsiOSHeadProject)' == 'true' " />

Launch, Build and Run

There, we’re done and ready to run out application. If you load the MultiTargetingwithUno solution file, you should see all five head projects, along with the shared project, and then two class libraries. In this mode you can pick any head project as the start up project and run that application. However, it will be slow as it will have to build every target framework for the Core and UI libraries.

iOS

If instead, you double-click the Launch.iOS.bat, it will restrict the target framework to just iOS and then launch the ios solution filter. The Solution Explorer only loads the iOS head project and the two class libaries and the build is significantly quicker as it’s only building for iOS.

Android

Next up is Android. Again by running the Launch.Android.bat you only see the Droid head project.

Windows (UWP)

Launch.Windows.bat will load the UWP project and again limit the build to only include the UWP target framework.

Web (WebAssembly / WASM)

The same process applies to WebAssembly (WASM).

MacOS

Finally for MacOS, the bat files won’t work (since they won’t run on Mac). However, you can still manually adjust the TargetsToBuildDeveloperOverride property and set it to Mac.

Solution filters aren’t supported yet by visual Studio for Mac, so you may consider creating a Mac specific solution file, rather than having to load all of the projects.

One really neat feature I noticed as i was debugging on Mac is that the application automatically supports theming – here’s screenshot running in Light and Dark mode. This also works on the other platforms!!

Now you’ve been through it, make sure you check out the raw source code at the GitHub repository

Cross-Platform Libraries with Multi-Targeting for Xamarin, Uno and Windows Development

The story of cross platform development for Microsoft developers has been one marked by iteration after iteration of .NET framework fragmentation. With .NET 5 the promise is that we’ll return to having a single framework that will be used everywhere…. Sorry, what?? when did we ever have a single framework? For as long as I … Continue reading “Cross-Platform Libraries with Multi-Targeting for Xamarin, Uno and Windows Development”

The story of cross platform development for Microsoft developers has been one marked by iteration after iteration of .NET framework fragmentation. With .NET 5 the promise is that we’ll return to having a single framework that will be used everywhere…. Sorry, what?? when did we ever have a single framework? For as long as I can recall, developers working on mobile and/or IoT have always had a different framework to target (.NET CF, .NET MF, WinPhone (whatever that .NET version was called), UWP etc). However, one thing that hasn’t changed is the fact that in order to target different platforms, you inevitably have to write code that’s specific to that platform. Even during the announcement of MAUI, the new single project structure has specific files/code etc for iOS, Android, Windows etc. This problem isn’t going away, so let’s discuss how we deal with this issue today.

The scenario I’m going to cover in the post is relatively simple. I have three “head” or “target platform” projects (Windows, Android, iOS) that are going to reference a common library (Core). Whilst most of the Core library is common code that is compatible with .NET Standard 2.0, there’s some code that is specific to each platform. Rather than create a separate platform specific library, we can include this specific logic by setting up the Core library to be multi-targeted – meaning that a different DLL is generated for each supported platform. Luckily Visual Studio knows how to handle this, so you’re not left working out how to reference each DLL from the head projects.

Project Setup

Let’s get started. First up, we’ll create a blank solution. If you start with one of the head projects your solution will end up being called something list XXX.Windows.

Search for Solution and select Blank Solution
Name your solution

Next up, let’s create the three head projects: Windows (UWP), Android and iOS

Search for UWP and select the Blank App (Universal Windows) template
Name you Windows head project – I like to use the Windows suffix but uwp is also often used
Search for droid and select the Android App (Xamarin) template
Name your Android head project
Search for iOS and select the iOS App (Xamarin) template
Name your iOS head project

At this point, if you’re working on a Mac, you could also add a MacOS project template. For some reason this template isn’t available in Visual Studio for Windows (because no developer would ever want to create the MacOS project when working on windows …. I guess the same (lack of) logic is used on VS for Mac where you can’t create a UWP project).

Next up, we’ll create the common library that each of the head projects will reference.

Search for .net standard and select the Class Library (.NET Standard) template
Name the .NET Standard library

Common Code

So that we can see how this library will work, we’ll simply expose a string constant that can be referenced and displayed in each head project. We’ll rename the Class1.cs file to AppProperties.cs and allow Visual Studio to rename the corresponding class. We’ll then add a string constant as follows:

namespace MultiTarget.Core
{
    public class AppProperties
    {
        public const string AppName = "MultiTarget Sample";
    }
}

In each of the head projects we’ll add an text/label element to the UI and set the value to be AppProperties.AppName. Rather than having to use the Add Reference workflow (i.e. right click on the head project and click Add Reference), we’ll simply type the AppProperties class name and use the prompt in the code editor to Add reference to the MultiTarget.Core project.

Type Ctrl+. to get the code editor suggestions to appear.

Now we can run each of the head projects and see the same output on the screen which should say “MultiTarget Sample” (I don’t have an iOS device/simulator handy, so I don’t have a screenshot of it running on iOS).

Android – MultiTarget Sample
Windows – MultiTarget Sample

Platform Specific Code

The next step is to add platform specific code. In this case we’re going to augment the existing AppProperties class by adding a platform specific partial class. In Solution Explorer we can copy the AppProperties.cs and paste it into the same project. The copied file can then be renamed based on the platform. For example (see image below) the Windows specific code would be in a file called AppProperties.windows.cs.

Note: The actual name of the platform specific files doesn’t have any intrinsic meaning. As we’ll see in a minute, we will use the platform specific suffix to define which files will be included for each platform.

Inside the platform specific file we’ll add another constant called PlatformName. For example, the AppProperties.windows.cs includes a PlatformName constant that returns “Windows.”

using System;

namespace MultiTarget.Core
{
    public partial class AppProperties
    {
        public const string PlatformName = "Windows";
    }
}

We’re also going to update the AppName constant in the AppProperties.cs file to include the PlatformName. We also needed to add the partial keyword to the class definition.

namespace MultiTarget.Core
{
    public partial class AppProperties
    {
        public const string AppName = "MultiTarget Sample - " + PlatformName;
    }
}

After adding files for each platform, if you attempt to build the Core project it will fail with an error indicating that there are multiple definitions of the PlatformName constant. What we need to do is to only include one platform specific file at a time.

MultiTarget Project

Currently the Core project is configured with a single TargetFramework, netstandard2.0. This means that the only API that can be accessed are those defined by netstandard2.0. If we want to include platform specific code, or want to access platform specific APIs, we need to change the project to target multiple frameworks. Here’s the current project XML for the Core library

<Project Sdk="Microsoft.NET.Sdk">
  <PropertyGroup>
    <TargetFramework>netstandard2.0</TargetFramework>
  </PropertyGroup>
</Project>

In order to target multiple frameworks, we can just change the TargetFramework element to TargetFrameworks, and add multiple frameworks, semicolon delimited (eg <TargetFrameworks>netstandard2.0;net451</TargetFrameworks> ). However, out of the box, this doesn’t support the various target framework monikers that are used across different platforms. To overcome this limitation, we need to change the Sdk attribute from “Microsoft.NET.Sdk” to “MSBuild.Sdk.Extras”. We also need to create a file called global.json in the solution folder with the following version information for the MSBuild.Sdk.Extra nuget package:

{
    "msbuild-sdks": {
        "MSBuild.Sdk.Extras": "2.0.54"
    }
}

Note: Alternatively you can specify the version number in the Sdk attribute (eg Sdk=”MSBuild.Sdk.Extras/2.0.54″ ).

With these changes made, we can update the project file to include multiple target frameworks:

<Project Sdk="MSBuild.Sdk.Extras">
	<PropertyGroup>
		<TargetFrameworks>netstandard2.0;xamarinios10;monoandroid10.0;</TargetFrameworks>
		<TargetFrameworks Condition=" '$(OS)' == 'Windows_NT' ">uap10.0.16299;$(TargetFrameworks)</TargetFrameworks>
	</PropertyGroup>
</Project>

Note: we’ve included a conditional TargetFrameworks element so that the Windows (i.e. UWP) target platform is only include if the host OS is Windows. This is important because the UWP platform can’t be built using Visual Studio for Mac, so making this target framework conditional on the OS ensures the project can be loaded and built using Visual Studio for Mac.

At this point it’s worth noting that by including additional target frameworks, you’re effectively increasing the number of steps in the build. For example, when we build the Core library, we see that four DLLs are built – effectively increasing the built time by four times!!!

The new project format includes all files nested in the project folder by default. This means that we need to change the default behaviour for the platform specific files so that they’re excluded by default. Then we can specifically include files for each platform that is built. The project file now looks like this:

<Project Sdk="MSBuild.Sdk.Extras">
	<PropertyGroup>
		<TargetFrameworks>netstandard2.0;xamarinios10;monoandroid10.0;</TargetFrameworks>
		<TargetFrameworks Condition=" '$(OS)' == 'Windows_NT' ">uap10.0.16299;$(TargetFrameworks)</TargetFrameworks>
	</PropertyGroup>

	<ItemGroup>
		<Compile Remove="**\*.netstandard.cs" />
		<Compile Remove="**\*.droid.cs" />
		<Compile Remove="**\*.ios.cs" />
		<Compile Remove="**\*.windows.cs" />
	</ItemGroup>

	<ItemGroup Condition=" $(TargetFramework.StartsWith('netstandard')) ">
		<Compile Include="**\*.netstandard.cs" />
	</ItemGroup>

	<ItemGroup Condition=" $(TargetFramework.StartsWith('xamarinios')) ">
		<Compile Include="**\*.ios.cs" />
	</ItemGroup>

	<ItemGroup Condition=" $(TargetFramework.StartsWith('monoandroid')) ">
		<Compile Include="**\*.droid.cs" />
	</ItemGroup>

	<ItemGroup Condition=" $(TargetFramework.StartsWith('uap')) ">
		<Compile Include="**\*.windows.cs" />
	</ItemGroup>
</Project>

And that’s it – building the Core library will result in four DLLs, each one having a different value for PlatformName, and thus AppName. We didn’t need to make any changes to the head projects.

This technique for including platform specific code in a common library is used by popular frameworks such as ReactiveUI and MvvmCross, as well as Microsoft libraries such as Xamarin Essentials.

Source code

Microsoft Build 2020: Uno Platform + WinUI = Future of Cross Platform Apps

I’ve been a long time supporter of the work that the team at Uno Platform have been doing. The announcement today of v3.0 of the Uno Platform comes hot on the heals of releases 2.3 and 2.4 that introduced AndroidX and MacOS support. This isn’t just any old announcement, v3 aligns the Uno Platform with … Continue reading “Microsoft Build 2020: Uno Platform + WinUI = Future of Cross Platform Apps”

I’ve been a long time supporter of the work that the team at Uno Platform have been doing. The announcement today of v3.0 of the Uno Platform comes hot on the heals of releases 2.3 and 2.4 that introduced AndroidX and MacOS support. This isn’t just any old announcement, v3 aligns the Uno Platform with the preview of WinUI 3.

At Built to Roam we’ve been building XAML based applications across a variety of technologies: WPF, Silverlight, WinPhone/Win8, UWP. Each iteration of Windows 10, new features were added to UWP but this limited the reach of the application to devices running the latest version of Windows 10. With WinUI 3.0 Microsoft is detaching the XAML platform away from the Windows version – this means that WinUI can iterate faster and bring newer controls and features to developers. In addition, WinUI also brings with it support for Win32 based applications – more on WinUI here.

So, why is it important that Uno Platform supports WinUI 3.0? Well, if you think of WinUI extending UWP to support all Windows 10 devices, then the addition of the Uno Platform takes WinUI across iOS, Android, macOS and Web via WebAssembly #WinUIEverywhere.

For more information, check out the Announcement of Uno Platform 3.0

Pipeline Templates: Complete Azure Pipelines Example for a Uno Project for iOS, Android and Windows

My last post was a bit of a long one as it covered a bunch of steps for setting up the bits and pieces required for signing an application for different platforms. In this post I just wanted to provide a complete example that shows a single multi-stage (6 in total) Azure Pipelines pipeline for … Continue reading “Pipeline Templates: Complete Azure Pipelines Example for a Uno Project for iOS, Android and Windows”

My last post was a bit of a long one as it covered a bunch of steps for setting up the bits and pieces required for signing an application for different platforms. In this post I just wanted to provide a complete example that shows a single multi-stage (6 in total) Azure Pipelines pipeline for building a Uno application for iOS, Android and Windows (UWP) and releasing them to App Center.

Secure Files

In my last post I showed how to create and populate Secure Files in Azure Pipelines. Any certificate or provisioning profile you need to use in your pipeline should be added to the Secure Files section of the Library in Azure Pipeline. My list of Secure Files looks like this:

Here we can see that we have the signing certificates for iOS and Windows, and the keystore for Android. Then we have two iOS provisioning profiles, one for my XF application and the other for my Uno application.

Variable Groups

I’ve extracted most of the variables I use in my pipeline into one of two variable groups:

The Common Build Variables are those variables that can be reused across multiple projects.

The Inspector Uno Build Variables are those variables that are specific to this project. For example it includes the AppCenter ids for the iOS, Android and Windows applications. It also includes the iOS provisioning profile which is specifically tied to this application.

Pipeline

Here’s the entire pipeline:

resources:
  repositories:
    - repository: builttoroam_templates
      type: github
      name: builttoroam/pipeline_templates
      ref: refs/tags/v0.5.0
      endpoint: github_connection

variables:
  - group: 'Common Build Variables'
  - group: 'Inspector Uno Build Variables'
  - name: ios_enabled
    value: 'true'
  - name: windows_enabled
    value: 'true'
  - name: android_enabled
    value: 'true'

stages:
- template:  azure/mobile/[email protected]_templates
  parameters:
    # Stage name and whether it's enabled
    stage_name: 'Build_Android'
    build_android_enabled: $(android_enabled)
    # Version information
    full_version_number: '$(version_prefix).$(Build.BuildId)'
    # Signing information
    secure_file_keystore_filename: '$(android_keystore_filename)'
    keystore_alias: '$(android_keystore_alias)'
    keystore_password: '$(android_keystore_password)'
    # Solution to build
    solution_filename: $(solution_file)
    solution_build_configuration: $(solution_build_config)
    # Output information
    artifact_folder: $(artifact_android_folder)
    application_package: $(android_application_package)

- template:  azure/mobile/[email protected]_templates
  parameters:
    # Stage name and dependencies
    stage_name: 'Deploy_Android'
    depends_on: 'Build_Android'
    deploy_appcenter_enabled: $(android_enabled)
    environment_name: $(appcenter_environment)
    # Build artifacts
    artifact_folder: $(artifact_android_folder)
    application_package: $(android_application_package)
    # Signing information (for Android repack to APK)
    secure_file_keystore_filename: '$(android_keystore_filename)'
    keystore_alias: '$(android_keystore_alias)'
    keystore_password: '$(android_keystore_password)'
    # Deployment to AppCenter
    appcenter_service_connection: $(appcenter_service_connection)
    appcenter_organisation: $(appcenter_organisation)
    appcenter_applicationid: $(appcenter_android_appid)


- template:  azure/mobile/[email protected]_templates
  parameters:
    # Stage name and whether it's enabled
    stage_name: 'Build_Windows'
    build_windows_enabled: $(windows_enabled)
    # Version information
    full_version_number: '$(version_prefix).$(Build.BuildId)'
    # Signing information
    windows_cert_securefiles_filename: '$(windows_signing_certificate_securefiles_filename)'
    windows_cert_password: '$(windows_signing_certificate_password)'
    # Solution to build
    solution_filename: $(solution_file)
    solution_build_configuration: $(solution_build_config)
    # Output information
    artifact_folder: $(artifact_windows_folder)
    application_package: $(windows_application_package)

- template:  azure/mobile/[email protected]_templates
  parameters:
    # Stage name and dependencies
    stage_name: 'Deploy_Windows'
    depends_on: 'Build_Windows'
    deploy_appcenter_enabled: $(windows_enabled)
    environment_name: $(appcenter_environment)
    # Build artifacts
    artifact_folder: $(artifact_windows_folder)
    application_package: $(windows_application_package)
    # Deployment to AppCenter
    appcenter_service_connection: $(appcenter_service_connection)
    appcenter_organisation: $(appcenter_organisation)
    appcenter_applicationid: $(appcenter_windows_appid)

- template:  azure/mobile/[email protected]_templates
  parameters:
    # Stage name and whether it's enabled
    stage_name: 'Build_iOS'
    build_ios_enabled: $(ios_enabled)
    # Version information
    full_version_number: '$(version_prefix).$(Build.BuildId)'
    # Solution to build
    solution_filename: $(solution_file)
    solution_build_configuration: $(solution_build_config)
    # Signing information
    ios_plist_filename: 'src/Apps/DotNet/Uno/InspectorUno/InspectorUno/InspectorUno.iOS/Info.plist'
    ios_cert_password: '$(ios_signing_certificate_password)'
    ios_cert_securefiles_filename: '$(ios_signing_certificate_securefiles_filename)'
    ios_provisioning_profile_securefiles_filename: '$(ios_provisioning_profile_securefiles_filename)'
    # Output information
    artifact_folder: $(artifact_ios_folder)
    application_package: $(ios_application_package)

- template:  azure/mobile/[email protected]_templates
  parameters:
    # Stage name and dependencies
    stage_name: 'Deploy_iOS'
    depends_on: 'Build_iOS'
    deploy_appcenter_enabled: $(ios_enabled)
    environment_name: $(appcenter_environment)
    # Build artifacts
    artifact_folder: $(artifact_ios_folder)
    application_package: $(ios_application_package)
    # Deployment to AppCenter
    appcenter_service_connection: $(appcenter_service_connection)
    appcenter_organisation: $(appcenter_organisation)
    appcenter_applicationid: $(appcenter_ios_appid)


Pipeline Templates v0.5.0

Most of the v0.5.0 release has been tidying things up, reducing the number of required parameters by making the template smarter and increasing consistency across the templates

Breaking Changes:

  • build-xamarin-android.yml – changed build_platform to solution_target_platform parameter
  • build-xamarin-windows.yml – changed build_platform to solution_target_platform parameter
  • build-xamarin-windows.yml – changed windows_appxupload_name parameter to windows_upload_name to reflect support for msix

Other Changes:

  • build-xamarin-[iOS/android/windows].yml – added depends_on parameter so that the stages can be ordered
  • build-xamarin-[iOS/android/windows].yml – artifact_name, artifact_folder and application_package are no longer required and have default values
  • build-xamarin-android.yml – supports building either aab or apk based on the application_package parameter
  • build-xamarin-windows.yml – windows_upload_name parameter isn’t required as it has a default value based on the bundle name
  • deploy-appcenter.yml – added conditions to all steps so that pipeline doesn’t break if build stage doesn’t generate any output
  • All template – documentation added to parameters and steps

Pipeline Templates: Building and Deploying Uno Apps for iOS, Android and Windows

In my previous posts covering the Pipeline Templates I’ve discussed building a Xamarin.Forms apps for iOS, Android and Windows (UWP) and subsequently deploying them to AppCenter. In this post we’re going to look at doing the same with a Uno application. Given that Uno is built on top of the core Xamarin functionality, the process … Continue reading “Pipeline Templates: Building and Deploying Uno Apps for iOS, Android and Windows”

In my previous posts covering the Pipeline Templates I’ve discussed building a Xamarin.Forms apps for iOS, Android and Windows (UWP) and subsequently deploying them to AppCenter. In this post we’re going to look at doing the same with a Uno application. Given that Uno is built on top of the core Xamarin functionality, the process for both build and deploy should be fairly similar. Rather than just stepping through using the template, I’m going to cover creating a new Uno project and setting up the corresponding multi-stage pipeline to build and deploy to AppCenter.

Also, I’ve pushed v0.3.0 of the pipeline templates, which I’ll summarise at the end of this post.

Creating a Uno Application

Let’s get into it and start by creating a Uno application. Before proceeding, make sure you grab the latest Uno extension for Visual Studio that includes the project templates. From the Create a new project dialog, enter “uno” into the search box and then select the Cross-Platform App (Uno Platform) template.

Next, enter a name and location for your new application

When you hit the Create button, Visual Studio will generate a new solution with five projects, representing the head projects for iOS, Android, Windows (UWP) and Web (WASM), along with a shared project.

After creating the application, you should go through each platform and check that it builds and runs. The WASM project will take a while to build and run the first time as it needs to download some components first – don’t be alarmed it nothing appears to happen for a long time.

Build Configuration

One thing I do like to tidy up for my applications is the build configurations. This is often overlooked by developers and then wonder why they have to wait around for say the Android project to build, when they have the UWP project selected as their start up project. Here are the Release configurations I have set for the different platforms

Release Configuration with Any CPU
Release Configuration with iPhone
Release Configuration with x64 (x86 and ARM platforms are the same except the Platform for InspectorUno.UWP is x86 and ARM respectively)

Building Uno Applications

We’ll go through each Uno application separately and I’ll endeavor to highlight typical pain points that developers face. If you’re using the pipeline_templates and you run into issues, message me on Twitter and I’ll help you out. Where there are common frustrations, I’ll work to improve the templates to make them easier to use.

Let’s start by creating a new pipeline in Azure DevOps. I’m not going to step through the pipeline wizard but for what we want to do, just select the appropriate source code respository and an empty YAML file. When you get to the YAML editor, enter the following.

trigger: none
resources:
  repositories:
    - repository: builttoroam_templates
      type: github
      name: builttoroam/pipeline_templates
      ref: refs/tags/v0.3.0
      endpoint: github_connection

variables:
  - group: 'Uno Build Variables'

There are three parts to this inital YAML. Firstly, we’re disabling the CI trigger whilst we’re configuring the build. As we’ll be committing changes to both the build pipeline and source code, it’s as well to only have builds triggered when you’re ready, otherwise you’ll be continually cancelling builds.

Next, the resources section is where we pull in the pipeline templates. In this case we’re targeting the v0.3.0 release to ensure the templates don’t change and break our builds in the future.

Lastly, we’re pulling in the Uno Build Variables variable group. You can pick whatever name you want for this group but it needs to match the name of the variable group defined under the Library tab on Azure DevOps.

Android – Build

Starting with Android we’re going to add stages to the YAML file (note you only need to include the stages element once and then add the individual stages by referencing the corresponding template). Here’s the Android build

stages:
- template:  azure/mobile/[email protected]_templates
  parameters:
    stage_name: 'Build_Android'
    build_android: $(android_enabled)
    solution_filename: 'src/Apps/DotNet/Inspector.Uno.sln'
    solution_build_configuration: 'Release'
    build_number: '$(Build.BuildId)'
    full_version_number: '$(version_prefix).$(Build.BuildId)'
    artifact_name: 'inspector-build'
    artifact_folder: 'Android_output'
    application_package: 'Inspector-Uno-Android.aab'
    secure_file_keystore_filename: '$(android_keystore_filename)'
    keystore_alias: '$(android_keystore_alias)'
    keystore_password: '$(android_keystore_password)'

There are a few things you need to have setup for this build to work:

  • solution_filename – make sure the path to your solution file is correct, relevant to the root of your code repository.
  • $(version_prefix) – make sure the version_prefix variable exists in your variable group and has the format X.Y (eg 1.0)
  • $(android_keystore_filename) – make sure the android_keystore_filename variable exists in your variable group and that it’s value matches the Secure file name of the keystore file uploaded to the Secure files under the Library in Azure DevOps.
  • $(android_keystore_alias) – make sure the android_keystore_alias variable exists in your variable group and that it is the the alias that you specified when creating the keystore. This variable should be marked as private by clicking the lock beside it in the portal – this hides it both in the variable group editor in the portal and in the log files.
  • $(android_keystore_password) – make sure the android_keystore_password variable exists in your variable group and that it is the password you specified when creating the keystore. Again this should be marked as private.

Frustratingly, the Android build didn’t just work for a couple of reasons:

  • Firstly, there was an issue where one of the images has a file name that isn’t supported by the version of Visual Studio and/or Android tooling on the windows-latest build agent, resulting in the following error:
    2020-02-08T06:04:55.7036355Z ##[error]src\Apps\DotNet\Uno\InspectorUno\InspectorUno\InspectorUno.Shared\Assets\Square44x44Logo.targetsize-24_altform-unplated.png(0,0): Error APT0003: Invalid file name: It must contain only [^a-zA-Z0-9_.]+.
    I simply excluded the file Square44x44Logo.targetsize-24_altform-unplated.png from the shared project
  • Secondly, the build agent include the Android NDK but doesn’t specify the appropriate environment variables (eg ANDROID_NDK_HOME), resulting in the following error:
    2020-02-07T12:56:19.5428557Z ##[error]C:\Program Files (x86)\Microsoft Visual Studio\2019\Enterprise\MSBuild\Xamarin\Android\Xamarin.Android.Common.targets(2843,3): Error XA5101: Could not locate the Android NDK. Please make sure the Android NDK is installed in the Android SDK Manager, or if using a custom NDK path, please ensure the $(AndroidNdkDirectory) MSBuild property is set to the custom path.
    The solution here was for me to update the build-xamarin-android.yml to include these environment variables. You shouldn’t run into this error if you’re using v0.3.0 of the pipeline templates.

Android – Deploy

Here’s the YAML for deploying the Android application to AppCenter

- template:  azure/mobile/[email protected]_templates
  parameters:
    stage_name: 'Deploy_Android'
    depends_on: 'Build_Android'
    environment_name: 'Inspector-Alpha'
    artifact_name: 'inspector-build'
    artifact_folder: 'Android_output'
    application_package: 'Inspector-Uno-Android.aab'
    appcenter_service_connection: 'AppCenterInspectorCI'
    appcenter_organisation: 'thenickrandolph'
    appcenter_applicationid: 'Inspector-Uno-Alpha'
    appcenter_release_notes: 'Release from deploy pipeline'
    secure_file_keystore_filename: '$(android_keystore_filename)'
    keystore_alias: '$(android_keystore_alias)'
    keystore_password: '$(android_keystore_password)'

Again there are a few things you need to check here but most importantly for this to work you need to setup an application in AppCenter. I created a new application

After creating the application, look at the url that appears in the browser. The piece highlighted in green is the value you need to set for the appcenter_organisation and the yellow is for the appcenter_applicationid.

You also need to make sure you setup a Service Connection between Azure DevOps and AppCenter (in this case it was given the name ‘AppCenterInspectorCI’ and assigned to the appcenter_service_connection property)

The other properties you need to check are:

  • depends_on – make sure this matches the stage_name property set on the android build stage
  • artifact_name, artifact_folder and application_package – make sure these match the corresponding value on the android build stage
  • secure_file_keystore_filename, keystore_alias and keystore_password – these should be set to the same as on the android build stage and are required so that the release process can extract and sign a fat apk from the aab file.

iOS – Build

Before we get into building your iOS application, let’s make sure you have both a signing certificate and a provisioning profile ready to go. If you have both of these, you can jump over the next two sections. These instructions can be stepped through on Windows, without the need for a Mac!

certificate

  • Install OpenSSL (Download from https://slproweb.com/products/Win32OpenSSL.html)
  • Open command prompt
  • Add OpenSSL to path (alternatively you can permanently add it to your Path environment variable if you want to have it accessible across all command prompts)
    set PATH=%PATH%;C:\Program Files\OpenSSL-Win64\bin\
  • Generate the signing request
    openssl genrsa -out ios_distribution.key 2048
    openssl req -new -key ios_distribution.key -out CertificateSigningRequest.certSigningRequest
  • Sign into the Apple Developer portal and go to Certificates (https://developer.apple.com/account/resources/certificates)
  • Click the + button to start the process of adding a new certificate
  • Select Apple Distribution from the list of certificate types and then Continue
  • Use the Choose File link to select the CertificateSigningRequest.certSigningRequest file you created in the previous steps, and then Continue
  • Important – Make sure you click the Download button to download your file. It’ll download as a file called distribution.cer unless you choose to rename it.
  • Move the distribution.cer file to the same folder that you’ve been working in
  • Complete the certificate creation from the command prompt (making sure you change PASSWORD to be a password of your choice)
    openssl x509 -in distribution.cer -inform DER -out ios_distribution.pem -outform PEM
    openssl pkcs12 -export -inkey ios_distribution.key -in ios_distribution.pem -out ios_distribution.p12 -passout pass:PASSWORD

With these steps completed you have a certificate file, ios_distribution.p12, which you can upload as a Secure File to Azure DevOps.

You’ll also need the signing identity, which we can get directly from the ios_distribution.pem that was generated along the way.
openssl x509 -text -noout -in ios_distribution.pem

Application Identifier

Before you can create a provisioning profile you need to setup an identity for your application in the Apple Developer portal. Go to the Identities tab and click on the + button to register a new application.

Select App IDs and then Continue

Enter both a Description and a Bundle ID. You may also need to select an App ID Prefix if you belong to a team. Next click Continue, followed by the Register button to complete the process of registering your application’s identity.

Note: Currently you will need to update the Info.plist file of your iOS application to set the CFBundleIdentifier to match the Bundle ID specified when creating the App ID.

Provisioning Profile

To create the provisioning profile, click on the Profiles tab in the Apple Developer portal. Click the + button to start the process of creating a new provisioning profile.

Select the Ad Hoc option under Distribution and then Continue.

Select the App ID that you previously created, then Continue

Select the certificate that needs to be used to sign the application, then Continue

Select the devices that will be able to install the application, then Continue

Give the provisioning profile a name and then click Generate.

Download the provisioning profile and add it as a Secure File in the Library in Azure DevOps. You’ll also need the provisioning profile id, which you can extract from the provisioning profile using any text editor. Open the provisioning profile and look for the UUID key; the string value immediately after it is the profile id.

Ok, we’re now ready for the build stage

- template:  azure/mobile/[email protected]_templates
  parameters:
    stage_name: 'Build_iOS'
    build_ios: true
    solution_filename: 'src/Apps/DotNet/Inspector.Uno.sln'
    solution_build_configuration: 'Release'
    ios_cert_password: '$(ios_signing_certificate_password)'
    ios_cert_securefiles_filename: '$(ios_signing_certificate_securefiles_filename)'
    ios_provisioning_profile_securefiles_filename: '$(ios_provisioning_profile_securefiles_filename)'
    build_number: '$(Build.BuildId)'
    full_version_number: '$(version_prefix).$(Build.BuildId)'
    ios_signing_identity: '$(ios_signing_identity)'
    ios_provisioning_profile_id: '$(ios_provisioning_profile_id)'
    artifact_name: 'inspector-build'
    artifact_folder: 'iOS_output'
    application_package: 'Inspector-Uno-iOS.ipa'

iOS – Deploy

The deploy stage is relatively simple

- template:  azure/mobile/[email protected]_templates
  parameters:
    stage_name: 'Deploy_iOS'
    depends_on: 'Build_iOS'
    environment_name: 'Inspector-Alpha'
    artifact_name: 'inspector-build'
    artifact_folder: 'iOS_output'
    application_package: 'Inspector-Uno-iOS.ipa'
    appcenter_service_connection: 'AppCenterInspectorCI'
    appcenter_organisation: 'thenickrandolph'
    appcenter_applicationid: 'Inspector-Uno-iOS-Alpha'
    appcenter_release_notes: 'Release from deploy pipeline'

Windows – Build

The build stage for Windows (UWP) is

- template:  azure/mobile/[email protected]_templates
  parameters:
    stage_name: 'Build_Windows'
    build_windows: true
    solution_filename: 'src/Apps/DotNet/Inspector.Uno.sln'
    solution_build_configuration: 'Release'
    uwpBuildPlatform: 'x86'
    build_number: '$(Build.BuildId)'
    full_version_number: '$(version_prefix).$(Build.BuildId)'
    windows_cert_securefiles_filename: '$(windows_signing_certificate_securefiles_filename)'
    windows_cert_password: '$(windows_signing_certificate_password)'
    artifact_name: 'inspector-build'
    artifact_folder: 'Windows_output'
    application_package: 'Inspector-Uno-Windows.msixbundle'
    windows_appxupload_name: 'Inspector-Uno-Windows.msixupload'

In order to build your Windows application you’re going to need a signing certificate. Microsoft has good documentation for creating the certificate which I would encourage you to follow. The important thing is to upload the certificate to the Secure files section under the Library tab on Azure DevOps and the corresponding password as a private variable. Damien Aicheh has a good tutorial on uploading certificates to Azure DevOps – don’t worry about the section on using the certificates as the Windows build template already does this for you.

Note: You also don’t need to worry about updating your package.appxmanifest so that the Publisher matches the Subject on the signing certificate. The Windows build template takes care of this too.

There are a couple of other parameters you’ll want to check off

  • uwpBuildPlatform – in this YAML this is only set to x86 for efficiency. If you’re planning to deploy your application to a range of devices, you should set this to x86|x64|ARM (this is the default value on the template so you can omit this property if you want to build for all three platforms)
  • $(windows_signing_certificate_securefiles_filename) – make sure the windows_signing_certificate_securefiles_filename variable exists in your variable group and that it’s value matches the Secure file name of the certificate (.pfx) file uploaded to the Secure files under the Library in Azure DevOps.
  • $(windows_signing_certificate_password) – make sure the windows_signing_certificate_password variable exists in your variable group and that it is password you specified when creating the certificate. This should be marked as private.

Note that the application package that we’re specifying here is an msixbundle. The Windows build pipeline has been upgraded to support both appx and msix bundles.

Windows – Deploy

The deploy stage for Windows (UWP) is

- template:  azure/mobile/[email protected]_templates
  parameters:
    stage_name: 'Deploy_Windows'
    depends_on: 'Build_Windows'
    environment_name: 'Inspector-Alpha'
    artifact_name: 'inspector-build'
    artifact_folder: 'Windows_output'
    application_package: 'Inspector-Uno-Windows.msixbundle'
    appcenter_service_connection: 'AppCenterInspectorCI'
    appcenter_organisation: 'thenickrandolph'
    appcenter_applicationid: 'Inspector-Uno-UWP-Alpha'
    appcenter_release_notes: 'Release from deploy pipeline'

Pipeline Templates v0.3.0

As promised, here’s a quick summary of the changes in v0.3.0. Technically this should have been a major version increment as there were some breaking changes but since we’re not at v1 yet, I’ve just pushed a minor update.

Breaking Changes:

  • build-xamarin-android.yml – change android_bundle_name parameter to application_package (for consistency with deploy-appcenter.yml)
  • build-xamarin-ios.yml – change ios_ipa_name parameter to application_package (for consistency with deploy-appcenter.yml)
  • build-xamarin-windows.yml – change windows_bundle_name parameter to application_package (for consistency with deploy-appcenter.yml)

Other Changes:

  • build-xamarin-android.yml – added environment variables (ANDROID_NDK_HOME, ANDROID_NDK_PATH, AndroidNdkDirectory) so that the build process can locate the NDK. This is required for Android builds that enable AOT compilation.
  • build-xamarin-android.yml: android_manifest_filename property no longer required – template will search for AndroidManifest.xml
  • build-xamarin-windows.yml: windows_package_manifest_filename property no longer required – template will search for *.appxmanifest
  • build-xamarin-ios.yml: ios_plist_filename property no longer required – template will search for Info.plist
  • build-xamarin-windows.yml: application_package supports both appxbundle and msixbundle file types. You need to make sure the filename matches the type of bundle your application is setup to create.

Visual State Management with BuildIt.States and Uno

I’ve posted previously on using visual states in Uno and how they can be used to effectively manage the different visual layouts a page can take on. These may be changes in layout due to the application being resized, or perhaps due to different data loading states. I’ve recently created a Uno build of the … Continue reading “Visual State Management with BuildIt.States and Uno”

I’ve posted previously on using visual states in Uno and how they can be used to effectively manage the different visual layouts a page can take on. These may be changes in layout due to the application being resized, or perhaps due to different data loading states. I’ve recently created a Uno build of the BuildIt.States library, BuildIt.States.Uno. In this post I’m going to walk through using this library to help manage visual states from within your view model.

One of the topics that’s quite hot at the moment is whether XAML has had its day and whether the new coded UI techniques provide a better solution. I’m not going to go too far into this debate but one of the things I really like about XAML is the separation of the UI (declared in XAML) from its data representation (the ViewModel).

Whilst the data binding framework of both UWP and Xamarin.Forms works well for connecting properties on a ViewModel to attributes of a UI element, there is no way to connect visual states on the page, with some aspect of the ViewModel. This is where the BuildIt.States library kicks in.

Thinking about Visual States

Before we get into using the BuildIt.States library, lets start by thinking through the different states that our page can go through. For the purpose of this post we’re going to build a simple app with the following spec:

  • The app has a single page that has a button, “Load Data”
  • When the button is pressed, the button will be hidden and a loading indicator will be shown.
  • The app will attempt to load some data.
  • Loading data will randomly succeed or fail
  • When loading is complete (either succeed or fail) the loading indicator will be hidden, a message will be displayed indicating success or failure, and the Load Data button will be displayed again.
  • If the Load Data button is pressed again, the status of the previous attempt will remain on screen until the new attempt to load data has been completed.

An initial read of this spec would seem to indicate that there is a single set of states:

  • Not Loading
  • Loading
  • Loaded – Success
  • Loaded – Failed

However, when the button is pressed for the second time, there are two more states that need to be included : Loading (Loaded – Success) and Loading (Loaded – Failed).

An alternative way of thinking about the states is that there is a group of states that pertain to whether data is being loaded, and a different group of states that pertain to whether the page has data:

LoadingStates

  • NotLoading
  • Loading

These states control whether the button or the loading indicator is visible

DataStates

  • NoData
  • Data
  • DataFailedToLoad

These states control the visibility of the data, or in this case the message indicating success or failure of the data loading.

Visual States in XAML

Since the focus of this post isn’t on how to design a page in XAML I’ll skip over the steps involved in laying out the page. In summary, after creating a new Uno project (using the Uno project templates), I opened the MainPage.xaml in Visual Studio Blend. Whilst Blend is a long way from being the design-first tool it was once envisaged as, it does still have support for defining visual states, which is sorely missing in Visual Studio (and probably the only reason I still use Blend).

Using the design surface in Blend I’m able to layout the various TextBlock, Button and ProgressRing to build the simple UI for the app. I then use the States tool window to create two Visual State Groups (LoadingStates and DataStates) and the associated Visual States for showing the appropriate elements. The resulting XAML looks like the following:

<Page x:Class="BuildItWithStatesForUno.MainPage"
      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
      xmlns:local="using:BuildItWithStatesForUno"
      xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
      mc:Ignorable="d">

    <Grid Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
        <VisualStateManager.VisualStateGroups>
            <VisualStateGroup x:Name="LoadingStates">
                <VisualState x:Name="NotLoading" />
                <VisualState x:Name="Loading">
                    <VisualState.Setters>
                        <Setter Target="LoadDataButton.(UIElement.Visibility)" Value="Collapsed" />
                        <Setter Target="LoadingProgress.(UIElement.Visibility)" Value="Visible" />
                        <Setter Target="LoadingProgress.(ProgressRing.IsActive)" Value="True" />
                    </VisualState.Setters>
                </VisualState>
            </VisualStateGroup>
            <VisualStateGroup x:Name="DataStates">
                <VisualState x:Name="NoData" />
                <VisualState x:Name="Data">
                    <VisualState.Setters>
                        <Setter Target="DataSuccessTextBlock.(UIElement.Visibility)" Value="Visible" />
                    </VisualState.Setters>
                </VisualState>
                <VisualState x:Name="DataFailedToLoad">
                    <VisualState.Setters>
                        <Setter Target="DataFailedTextBlock.(UIElement.Visibility)" Value="Visible" />
                    </VisualState.Setters>
                </VisualState>
            </VisualStateGroup>
        </VisualStateManager.VisualStateGroups>
        <StackPanel HorizontalAlignment="Center"
                    VerticalAlignment="Center">
            <TextBlock x:Name="DataSuccessTextBlock"
                       Margin="20"
                       FontSize="40"
                       Foreground="Green"
                       Text="Data Loaded Successfully!"
                       TextAlignment="Center"
                       Visibility="Collapsed" />
            <TextBlock x:Name="DataFailedTextBlock"
                       Margin="20"
                       FontSize="40"
                       Foreground="Red"
                       Text="Data Failed to Load"
                       TextAlignment="Center"
                       Visibility="Collapsed" />
            <Grid Margin="50">
                <Button x:Name="LoadDataButton"
                        HorizontalAlignment="Center"
                        Click="LoadDataClick"
                        Content="Load Data"
                        FontSize="30" />
                <ProgressRing x:Name="LoadingProgress"
                              Width="50"
                              Height="50"
                              Foreground="Blue"
                              IsActive="False"
                              Visibility="Collapsed" />
            </Grid>
        </StackPanel>
    </Grid>
</Page>

Testing the Visual States

Before moving on I wanted to test that the Visual States work, so I wired up the Load Data button with an event handler so I could switch the visual states:

private async void LoadDataClick(object sender, RoutedEventArgs e)
{
    var loadTimeInMilliseconds = rnd.Next(1000, 10000);
    var success = loadTimeInMilliseconds % 2 > 0;
    VisualStateManager.GoToState(this, "Loading", true);
    await Task.Delay(loadTimeInMilliseconds);
    VisualStateManager.GoToState(this, "NotLoading", true);
    VisualStateManager.GoToState(this, success ? "Data" : "DataFailedToLoad", true);
}

Clearly this code isn’t production ready (string literals, codebehind, no error handling etc) but when I run the app, I can see the desired state changes. Here I’m just showing Android but since it’s Uno, it should work nicely on iOS, UWP and WASM too.

Visual States in Action (Gif captured and generated using Snagit from TechSmith)

ViewModel States

Now that we’ve defined the visual states, we need a way to both control and track the states in our ViewModel. In the same way that we can use data binding to update attributes of the visual elements on the page, we need a way to mirror visual states within our ViewModel. This is where we can make use of the StateManger from the BuildIt.States library.

In the following MainViewModel, a StateManager is created and setup using two different state groups. Rather than using string literals, we use an enum to define each state group. Note that each enum has a Base value, which reflects the default, or unset, state.

public enum LoadingStates
{
    Base,
    NotLoading,
    Loading
}

public enum DataStates
{
    Base,
    Data,
    DataFailedToLoad
}

public class MainViewModel : IHasStates
{
    private readonly Random rnd = new Random();

    public IStateManager StateManager { get; } = new StateManager();

    public MainViewModel()
    {
        StateManager
            .Group<LoadingStates>()
            .DefineAllStates()
            .Group<DataStates>()
            .DefineAllStates();
    }

    public async Task LoadData()
    {
        var loadTimeInMilliseconds = rnd.Next(1000, 10000);
        var success = loadTimeInMilliseconds % 2 > 0;

        await StateManager.GoToState(LoadingStates.Loading);
        await Task.Delay(loadTimeInMilliseconds);
        await StateManager.GoToState(LoadingStates.NotLoading);
        await StateManager.GoToState(LoadingStates.Loading);
        await StateManager.GoToState(success ? DataStates.Data : DataStates.DataFailedToLoad);
    }
}

I also need to update the codebehind in MainPage to create an instance of MainViewModel and then invoke the LoadData method when the Load Data button is clicked:

public sealed partial class MainPage : Page
{
    public MainViewModel ViewModel => DataContext as MainViewModel;

    public MainPage()
    {
        this.InitializeComponent();

        DataContext = new MainViewModel();
    }
    private async void LoadDataClick(object sender, RoutedEventArgs e)
    {
        await ViewModel.LoadData();
    }
}

Connecting ViewModel to Visual States

Of course, if we run the code at this point, the state tracked within the MainViewModel don’t update the UI. To complete the loop, we need to attach another StateManager to the visual states defined on MainPage, and then bind the two StateManagers so that they can remain in sync. This is all done in the MainPage codebehind.

public sealed partial class MainPage : Page
{
    public MainViewModel ViewModel => DataContext as MainViewModel;
    private IStateManager StateManager { get; } = new StateManager();

    public MainPage()
    {
        this.InitializeComponent();

        DataContext = new MainViewModel();

        StateManager
            .Group<LoadingStates>()
            .DefineAllStates(this,this.LoadingStates)
            .Group<DataStates>()
            .DefineAllStates(this, this.DataStates);

        StateManager.Bind(ViewModel.StateManager);
    }
    private async void LoadDataClick(object sender, RoutedEventArgs e)
    {
        await ViewModel.LoadData();
    }
}

And there we go – now when you run the application and press the Load Data button the LoadData method on the MainViewModel will be invoked. As the states of the MainViewModel change, the StateManager and subsequently the visual states on the MainPage are updated.

Do Uno Mvvm?

Last week was a huge week for the Uno platform with their inaugural Uno conference, #UnoConf. As the technology continues to mature, I’ve no doubt that Uno will become a viable solution for building applications to target all sorts of markets. This includes support being progressively added by the various Mvvm frameworks. Following my previous … Continue reading “Do Uno Mvvm?”

Last week was a huge week for the Uno platform with their inaugural Uno conference, #UnoConf. As the technology continues to mature, I’ve no doubt that Uno will become a viable solution for building applications to target all sorts of markets. This includes support being progressively added by the various Mvvm frameworks.

Following my previous posts (MVVM Navigation with Xamarin.Forms Shell and MVVM Navigation with Xamarin.Forms Shell – Part II) where I discussed a simple approach to Mvvm with Xamarin.Forms, I figured I’d so something similar with Uno.

Mvvm with Uno

Let’s get on with it and start with a new Uno project – Download and install the Uno Platform Solution Templates extension from the Visual Studio marketplace, if you haven’t already. In Visual Studio, create a new project based on the Cross-Platform App (Uno Platform) project template. I’m going to call the app DoUnoMvvm.

Creating a Class Library

We’re going to separate out our viewmodels and services into a separate library, so add a new project, DoUnoMvvm.Core, based on the Class Library (.NET Standard) project template. Delete the class1.cs and then add a reference to the class library to each of the head projects (i.e. Droid, iOS, UWAP and Wams).

Adjusting NuGet Package References

Right-click on the solution node in the Solution Explorer window and select Manage NuGet Packages for Solution. Go to the Updates tab, check the Include prerelease option and then check the box alongside the packages Uno.Wasm.Bootstrap, Uno.UI, Microsoft.NETCore.UniversalWindowsPlatform and Uno.Core (don’t check either the Logging packages). Click Update to get the latest version of the packages that are checked.

From the Browse tab on the NuGet-Solution window used in the previous step, enter BuildIt.General.Uno into the search box. Select BuildIt.General.Uno and install the packages into all five of the projects.

Mvvm Basics with ViewModelLocator

Now we should be ready to start writing some code. We’re going to keep it simple with the following steps:

  • Create ViewModelLocator class – used for serving up viewmodels and creating services as required
  • Create an instance of ViewModelLocator in App Resources, making it accessible as a static resource in XAML
  • Create MainViewModel class – the viewmodel for the existing MainPage
  • Update ViewModelLocator with a property Main that returns an instance of the MainViewModel class
  • Set the DataContext of the MainPage to use the Main property on the ViewModelLocator
  • Run the application and show data is being served by the MainViewModel.

Here we go…. firstly a new ViewModelLocator class, which is added to the DoUnoMvvm.Core project

public class ViewModelLocator
{
}

Update App.xaml to create an instance of the ViewModelLocator class

<Application
    x:Class="DoUnoMvvm.App"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:local="using:DoUnoMvvm"
    xmlns:core="using:DoUnoMvvm.Core"
    RequestedTheme="Light">
  <Application.Resources>
    <core:ViewModelLocator x:Key="ViewModelLocator" />
  </Application.Resources>
</Application>

Now to create the MainViewModel, also in the DoUnoMvvm.Core project. We’ll create a property, WelcomeText, that will return some data to be displayed on MainPage.

public class MainViewModel
{
    public string WelcomeText => "How well do Uno Mvvm?";
}

We need to update the ViewModelLocator class to include the Main property

public class ViewModelLocator
{
    public MainViewModel Main => new MainViewModel();
}

And use this property when setting the DataContext for MainPage. I’ve also updated the TextBlock to be data bound to the WelcomeText property.

<Page
    x:Class="DoUnoMvvm.MainPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:local="using:DoUnoMvvm"
    xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
    xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
    DataContext="{Binding Main, Source={StaticResource ViewModelLocator}}"
    mc:Ignorable="d">

  <Grid Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
    <TextBlock Text="{Binding WelcomeText}" Margin="20" FontSize="30" />
  </Grid>
</Page>

Run the application and there we have it, our first data bound page

Quick Navigation using Event Mapping

That’s pretty much the basics of Mvvm. However, following my previous posts discussing navigation, I just want to demonstrate how to abstract navigation away from both the page and the viewmodel – this allows for more independent testing of viewmodels as there’s no interdependency between viewmodels. Here’s the basic process:

  • Add a new page, SecondPage, that we’re going to navigate to
  • Add a corresponding viewmodel, SecondViewModel, and property, Second, on the ViewModelLocator
  • Update SecondPage to set the DataContext to be bound to the Second property on the ViewModelLocator
  • Add a Button to MainPage that invokes a method, Next, on the MainViewModel
  • Add an event, Complete, to MainViewModel, and raise it from the Next method.
  • Add a mapping to the App.xaml.cs that navigates to SecondPage when the Complete method is raised.

And here’s the code. I’m not going to show you the initial SecondPage as it’s just generated from the template and you’ll see it later anyhow. Instead, we’ll jump to the SecondViewModel (if you’re following along you still need to add the SecondPage to the DoUnoMvvm.Shared project in the Pages folder).

public class SecondViewModel
{
    public string ProgressText => "Now you know how to navigate....";
}

Add the Second property to the ViewModelLocator

public class ViewModelLocator
{
    public MainViewModel Main => new MainViewModel();
    public SecondViewModel Second => new SecondViewModel();
}

Now back to the SecondPage and I have set the DataContext and bound the TextBlock.

<Page
    x:Class="DoUnoMvvm.Shared.Pages.SecondPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:local="using:DoUnoMvvm.Shared.Pages"
    xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
    xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
    mc:Ignorable="d"
    DataContext="{Binding Second, Source={StaticResource ViewModelLocator}}"
    Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
  <Grid>
    <TextBlock Text="{Binding ProgressText}" />
  </Grid>
</Page>

Now a Button to invoke the transition from MainPage to SecondPage

<Page
    x:Class="DoUnoMvvm.MainPage" ...
    DataContext="{Binding Main, Source={StaticResource ViewModelLocator}}" >
  <StackPanel>
    <TextBlock Text="{Binding WelcomeText}" Margin="20" FontSize="30" />
    <Button Content="Go to Second Page" Click="GoNextClick" />
  </StackPanel>
</Page>

Here we’re simply using a code behind but you could easily use a command. Unfortunately x:Bind doesn’t appear to be working with Uno yet, so you can’t simply bind the Click method to a method on the viewmodel.

public void GoNextClick(object sender, RoutedEventArgs e)
{
    (DataContext as MainViewModel)?.Next();
}

The Next method simply raises the Complete event

public class MainViewModel
{
    public event EventHandler Complete;

    public string WelcomeText => "How well do Uno Mvvm?";

    public void Next()
    {
        Complete?.Invoke(this, EventArgs.Empty);
    }
}

The final step is to add the mapping to App.xaml.cs to define what happens when the Complete event is triggered on the MainViewModel. Add the following property and method to App.xaml.cs, and update the App class to implement the IApplicationWithMapping interface (which comes from the BuildIt.General.Uno library that you should have added earlier)

public IDictionary<Type, IEventMap[]> Maps { get; } = new Dictionary<Type, IEventMap[]>();
private void MapPageTransitions()
{
    Maps.For<MainViewModel>()
        .Do(new EventHandler((s, args) => (Windows.UI.Xaml.Window.Current.Content as Frame)?.Navigate(typeof(SecondPage))))
        .When((vm, a) => vm.Complete += a, (vm, a) => vm.Complete -= a);
}

Invoke the MapPageTransitions method immediately after the Window.Current.Content property has been set equal to a new Frame. In order for the events to get correctly wired up you also need to update both MainPage and SecondPage to inherit from the MappingBasePage class.

Now when you run the application, MainPage will appear with a Button that you can click to navigate to the SecondPage.

Uno How to Mvvm!

You might be thinking…. you’ve just shown me how to do a bunch of UWP code… and that is EXACTLY the point. If you switch to the Droid or iOS or Wasm target, you can run the same application on each of those platforms with NO further code changes required. The Uno platform is about leveraging the skills you already have as a UWP (or as a Xamarin.Forms) developer, allowing you to build rich, high-quality applications for iOS, Android and Web.

Link to the source code

Installing Uno as a PWA with WebAssembly

One of the things that I don’t like about the web is that I have to access everything via the browser. Whilst favourites and bookmarks are all well and good, one of the nice things about apps is that I can do things like pin to start/taskbar (Windows) or add to homescreen (Android). Sure I … Continue reading “Installing Uno as a PWA with WebAssembly”

One of the things that I don’t like about the web is that I have to access everything via the browser. Whilst favourites and bookmarks are all well and good, one of the nice things about apps is that I can do things like pin to start/taskbar (Windows) or add to homescreen (Android). Sure I can pin a website, but this leads me to my next point – it still feels like the web, rather than an app experience. There’s still the browser chrome that sits around the edge and it doesn’t feel the same as being in an app. In this post we’re going to look at one aspect of Progressive Web Applications (PWA) which is the ability to “install” the application in order to address some of my feelings towards web applications.

Twitter PWA

Let me start by walking through one of the better PWA experiences offered by Twitter. Over the last couple of months Twitter has changed the layout of their website significantly but what’s interesting is that it appears they’ve been moving towards a single look and feel across both their web and app experience. For example, the experience you see today on the website is basically the same as what you get if you download the Windows Store app. As you’ll see once we install their PWA that the web interface makes sense because it’s designed to work as an app.

Back in 2017, Twitter announced Twitter Lite which they talked about as being a PWA. They talked a lot about how they built it and their post is definitely worth a read. However, I want to focus on the experience they’ve built for users.

Twitter on Mobile Chrome

Let’s look first at their mobile experience. When you go to mobile.twitter.com in Chrome on a mobile device, assuming you’ve signed in, you’ll see a prompt at the bottom of the screen to “Add Twitter to Home screen”. Alternatively if you’re not signed in, or you’ve dismissed the prompt, you can select Add to Home Screen from the side menu in Chrome.

Tapping on Add Twitter to Home screen displays a confirmation prompt

Tapping Add will “install” the mobile website as an application. This includes an icon that you can move around your home screen. Note that the icon is almost indistinguishable from the actual Twitter application that you can download from the store.

When you launch the newly installed Twitter website, what you see is virtually the same as the Twitter application you’d download from the store. There’s no browser chrome and it looks and behaves just like an app.

And in fact if you press and hold on the Twitter icon on the home screen and go to App info, it even displays information in the same way as it would a regular application, including the ability to Uninstall and Force stop.

Twitter on Desktop Chrome

So that’s the mobile experience. Let’s just check what the desktop experience is. It’s not much different, except for there’s no prompt to install the application. However, if you look to the right of the address bar, there’s a little circle with a plus button; hovering over it indicates it will Install Twitter. Similarly if you go to the right side-menu, there’s an option to Install Twitter.

Again, the install process prompts for user confirmation.

Once installed the Twitter website launches without the browser chrome. In addition to the usual minimize, restore and close buttons on the right side of the title bar of the window, there’s a key icon and a vertical dots icon. The key icon allows you to clear all browsing data.

The vertical dots reveals a menu with the option to Uninstall Twitter.

After installing the Twitter website as an application the Twitter icon does appear in the applications list. However, if you attempt to uninstall the Twitter website by right-clicking the icon and selecting uninstall, it’ll just take you to Add/Remove programs in Settings (I suspect Windows thinks you want to uninstall Chrome). You need to launch the Twitter website application and use the Uninstall Twitter option in the menu.

Making Uno a PWA

Now that we’ve seen how a website can be installed and then behaves just like a regular application, let’s take a look at how easily we can do this for an application that uses Uno and WebAssembly.
The firs thing that we’ll need is a manifest file. In my case I’ve called it manifest.json and I’ve put it into the root of the WASM project in my Uno solution. It’s got the following content that defines things like the icon and the name of application etc.

{
    "background_color": "#ffffff",
    "description": "Freakin awesome Uno web app.",
    "display": "standalone",
    "icons": [
      {
        "src": "Icon192x192.png",
        "sizes": "192x192",
        "type": "image/png"
      }

    ],
    "name": "Uno as a PWA",
    "short_name": "Uno PWA",
    "start_url": "/index.html",
    "theme_color": "#ffffff",
    "scope": "/"
}

Of course, we’ll need to add the icon – I’ve added an 192×192 png with the name Icon192x192.png to the wwwroot folder within the WASM project. I also need to connect the manifest file so that the browser knows to look for it. To do this I need to add it as a link to the web page that hosts the Uno WASM application. In the default WASM project generated by the Uno solution template, there’s no html file, since it’s automatically generated. From the Uno documentation it’s possible to add in a template html file (see the Index.html content override section in the Bootstrap readme). However, it’s also possible to just specify the name of the manifest file using the WasmPWAManifestFile attribute in the project file (see Support for PWA Manifest File section in docs).

<WasmPWAManifestFile>manifest.json</WasmPWAManifestFile>

When we now run the WASM project and bring up the developer tools on the Application tab you can select Manifest and see the information contained in the manifest.json.

Also, the plus button is on the right of the address bar (and the option to Install in the side menu), indicating that this website can be installed.

And that’s it – all you need to do to get your Uno website setup to be installed as as PWA.

Content from Former Microsoft WPF and Silverlight Team Member

Someone pointed me in the direction of a series of great blog posts that have recently been migrated to a github repository. The posts are quite old, dating back to a period between 2005 and 2013 when Beatriz Stollnitz worked for Microsoft as part of the WPF and Silverlight teams. Here are the links to … Continue reading “Content from Former Microsoft WPF and Silverlight Team Member”

Someone pointed me in the direction of a series of great blog posts that have recently been migrated to a github repository. The posts are quite old, dating back to a period between 2005 and 2013 when Beatriz Stollnitz worked for Microsoft as part of the WPF and Silverlight teams. Here are the links to each of the posts – happy reading!

Update 11th August: I’ve forked the repository and have started to work my way through the sample code to a) update it to WPF on .NET 4.7.2 and b) provide a similar example for UWP + Uno (iOS, Android, WASM). Feel free to check it out and help out!

01-DataContext

02-EmptyBinding

03-GetListBoxItem

04-BindToComboBox

05-DisplayMemberPath

06-SelectedValue

07-ChangePanelItemsControl

08-BarGraph

09-CollectionViewSourceSample

10-MasterDetail

11-MasterDetailThreeLevels

12-DataBoundDialogBox

13-TemplatingItems

14-SortingGroups

15-GroupingTreeView

16-GroupByType

17-BoundListView

18-ThreeLevelMasterDetailADO

19-ObjectDataProviderSample

20-InsertingSeparators

21-CustomSorting

24-AsynchronousBinding

25-BindToEnum

26-DataTriggerSample

27-ConvertXaml

28-FilterSample

29-MultipleFilters

30-MultiBindingConverter

31-ChangesMultithreading

32-PolygonBinding

33-PolygonBinding2

34-PolygonBinding3

35-CommonQuestions

36-ADOIndependentView

37-PlanetsListBox

38-UpdateExplicit

39-TreeViewPerformancePart1

40-TreeViewPerformancePart2

41-TreeViewPerformancePart3

42-WPFPresenter

43-BindToXLinq

44-XLinqXMLMasterDetail

45-DebuggingDataBinding

46-DragDropListBox

47-ExpandTreeViewPart1

48-ExpandTreeViewPart2

49-ExpandTreeViewPart3

51-UIVirtualization

52-DataVirtualization

54-PieChartWithLabels

55-PieChartWithLabelsSilverlight

56-PieChartWithLabelsSilverlight

57-DataVirtualization

58-MultipleStyles

59-WPFCollectionViewSource

60-SLCollectionViewSource

61-OredevComputerWeekly

62-DataVirtualizationFiltering

64-DataVirtualizationFilteringSorting

66-SortingHierarchy

67-PieChartWithLabelsUpdates

69-BindRadioButtonsToEnumsPart1

70-BindRadioButtonsToEnumsPart2

71-BindRadioButtonsToEnumsPart3

72-BindRadioButtonsToEnumsPart4

73-BindRadioButtonsToEnumsPart5

74-PositioningDataBoundItems

75-SimultaneousEnableDisable

76-FocusWatcher

77-CaptureWatcher

78-BetterBindableBase

79-BooleanConverters

Using the UWP SplitView on iOS, Android and WebAssembly with Uno

In this post we’re going to cover one of the basics of app navigation which is the use of the UWP SplitView. If you’re coming from iOS and Android development you might be thinking “huh, I don’t even know what that is.” Well the good news is that it’s actually something you’re already familiar with. … Continue reading “Using the UWP SplitView on iOS, Android and WebAssembly with Uno”

In this post we’re going to cover one of the basics of app navigation which is the use of the UWP SplitView. If you’re coming from iOS and Android development you might be thinking “huh, I don’t even know what that is.” Well the good news is that it’s actually something you’re already familiar with. Whether you’re used to an app that has a master-details layout, or one that uses a burger menu to display a flyout menu, these can both be implemented using the UWP SplitView.

One thing to be aware of is that the UWP SplitView is one of the basic controls that was added early in the UWP lifecycle. Since then there have been other controls added, such as the NavigationView and the MasterDetailsView (Windows Community Toolkit) that provide extended functionality and are worth exploring depending on the requirements of your project.

New Project – Cross-Platform App (Uno Platform)

Let’s get into it – we’re going to start with creating a new project based on the latest Uno Visual Studio Extension (updated at end of July – if you’re using an older version I would recommend updating). I’m also working with the Visual Studio 2019 (16.3 preview 1.0) as this provides the best support for working with WebAssembly.

Cross-Platform App using the Uno Solution Template

Once you’ve created your solution, I would highly recommend that you a) update NuGet references and b) go through each platform and make sure you can build and run the application. However, as at the time of writing do NOT update the Microsoft.Extensions.Logging.* packages – there’s a note in the csproj files that states “Note that for WebAssembly version 1.1.1 of the console logger required.” My recommendation is to leave these packages at v1.1.1 across all projects. For the Uno libraries I pick the latest prerelease versions but be warned that this occasionally backfires as you may get an unstable version – this is why it’s important to run each platform before proceeding!!

Note: One issue I’m currently seeing in the Uno template is that it generates assets (i.e. images) with names that include the scale factor eg scale-200. This is fine for UWP but fails to build for Android. I’ve gone through and just removed the scale factor from the filenames. You’ll need to rebuild your UWP project to make sure it picks up the filename changes correctly.

Note 2: When running the WebAssembly (aka WASM) project, make sure you select “Start without Debugging” in Visual Studio.

Note 3: When running the iOS build you may need to set the Deployment Target in the Info.plist. If you’re using the latest preview of Visual Studio it will pick up iOS 12.4 on the build agent which will cause you app to fail to deploy if you haven’t set the Deployment Target.

Adding the UWP SplitView

Now that we have our new application up and running, it’s time to add the SplitView control.

Design in Blend

For this we’re going to switch over to Blend – yeh, the product still exists and you’ll see in a minute why we’re going to be using it. To make the switch, right-click on the MainPage.xaml in the shared project and select Design in Blend.

Switching to Design in Blend

Switching to Blend will take a few seconds, particularly if this is the first time you’ve ever opened Blend. You’ll also see errors as the iOS and Android projects won’t open – ignore these and don’t worry about the upgrade log that will popup (these are irritating but can be safely ignored as they won’t impact your project).

Despite selecting Design in Blend from the MainPage.xaml, once in Blend, you’ll actually need to use the Solution Explorer window to open MainPage.xaml in the designer. Once you’ve opened MainPage.xaml, Blend should feel fairly familiar, even if this is the first time you’ve used it. This is because a lot of the windows are shared with Visual Studio – the separation between the products is a mix of legacy (don’t want to disrupt the tiny percentage of developers who still use it) and the optimising that design tasks will be done using Blend.

Blend Designer

Adding the SplitView

There are a number of ways to add the SplitView control into the MainPage. If you’re familiar with writing XAML it’s probably just easiest to add the SplitView element. However, to build familiarity with Blend, let’s add the SplitView using the designer. In the Assets window, enter “splitview” to locate the SplitView control. Use the mouse to drag the SplitView down to the Objects and Timeline window at the position in the hierarchy where you want it to appear. In this case we’re going to drop it inside the existing Grid – I typically have a Grid as the root of most pages to allow setting of background and other properties using a application-wide style, independently of what content is nested within the Grid.

Adding the UWP SplitView

Adding the SplitView this way will add it as the second child of the Grid, immediately following the existing TextBlock. As we want the SplitView to take up the entire space of the page, we’re going to move the TextBlock in the main content area by dragging the TextBlock into the Grid that is nested within the SplitView. The XAML of the page should now look like the following:

<Page
    x:Class="UwpSplitViewSample.MainPage"
    xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
    xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
    xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
    xmlns:local="using:UwpSplitViewSample"
    xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
    mc:Ignorable="d">
    <Grid Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
        <SplitView>
            <SplitView.Pane>
                <Grid />
            </SplitView.Pane>
            <Grid>
                <TextBlock
                    Margin="20,20,20,20"
                    FontSize="30"
                    Text="Hello, world !" />
            </Grid>
        </SplitView>
    </Grid>
</Page>

The SplitView is made up of two distinct areas: the main content area and the pane that can be shown/hidden (i.e. the flyout). From this code we can see that the SplitView as two nested XAML elements which align to the SplitView areas. The first is the SplitView.Pane which defines the layout of the content that will appear within the pane/flyout of the SplitView. The second defines the layout of content to appear within the main content area of the SplitView, in this case a Grid with a TextBlock contained within it.

Adjusting Layout with Blend

I’ll repeat this: For those of us familiar with writing XAML, you’ll find that manually crafting XAML is by far the quickest way to add and edit elements. However, Blend provides a number of shortcuts for positioning elements that can come in handy. Some of which we’ll cover here.

Designing the SplitView Pane

For the purpose of this post, all we’re going to do is to add a StackPanel with a TextBlock and Button as children to both the SplitView.Pane and the SplitView. The TextBlock will be used to indicate what part of the SplitView it is (Pane or Content) and the Button will be used to Show and Hide the pane of the SplitView.

Let’s start with the SplitView.Pane which already has a Grid element. In the Objects and Timeline window, right-click on the Grid and select Change Layout Type, followed by StackPanel.

Change Layout Type to StackPanel

You should see the Grid change to StackPanel and remains selected in the Objects and Timeline window. Next, with the StackPanel still in focus, use the Assets window to locate the TextBlock and double-click on TextBlock to add a TextBlock as a child to the StackPanel. Repeat, this time for a Button.

We’re going to position the StackPanel in the centre of the SplitView pane. To do this, again keep the StackPanel selected in the Objects and Timeline window, we’re going to go to the Properties window and scroll down to the Layout section at set the HorizontalAlignment and VerticalAlignment properties to Center.

Centering the StackPanel

Whilst we’re using the Properties window, select the TextBlock and change the Text property to “Pane”, and then select the Button and change the Content property to “Hide Pane” (Note that unlike Xamarin.Forms that has a Text property, to set the text on a Button in UWP XAML you need to set the Content property).

The last thing we’re going to do with the XAML for the SplitView.Pane is to add an event handler to the Click event of the Button. With the Button selected in the Objects and Timeline window, go to the Properties window, and click on the lightning bold icon to switch from properties to events view. Locate the Click event and type the name of the event handler you want to create, in this case PaneButtonClick. When you press Enter the PaneButtonClick method will be created in the MainPage.xaml.cs code behind file and the XAML will be updated with the Click property.

Adding an Event Handler for the Click Event

For the moment, that’s where we’ll leave the XAML for the SplitView.Pane and we’ll implement the logic for the Click event handler shortly.

Designing the SplitView Content

The layout of the SplitView content is going to be very similar to that of the pane: A StackPanel with nested TextBlock and Button. However, we’re going to go about it slightly differently, considering the fact that we already have a TextBlock nested in a Grid in the content area. We’re going to start by wrapping the TextBlock in a StackPanel. To do this, right-click somewhere in the TextBlock on the designer and select Group Into, followed by StackPanel (this also works if you right-click on the TextBlock in the Objects and Timeline window).

After doing this the hierarchy of elements in the SplitView content will be Grid, StackPanel, TextBlock. However, if you look at the XAML you’ll notice that Blend has added some additional attributes, setting the Margin on the StackPanel and the Height and Width on the TextBlock. To remove these, we can just right-click the StackPanel and select Layout, followed by Reset All. Repeat this on the TextBlock.

From here we can repeat the remaining steps that we did for the SplitView pane:

  • Add a Button to the StackPanel
  • Set HorizontalAlignment and VerticalAlignment on the StackPanel to Center
  • Set Text on the TextBlock to “Content Area”
  • Set Content on the Button to “Show Pane”
  • Add an event handler called ShowPaneButtonClick to the Button Click event

The final XAML in MainPage.xaml should look similar to:

<Page x:Class="UwpSplitViewSample.MainPage"
      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
      xmlns:local="using:UwpSplitViewSample"
      xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
      mc:Ignorable="d">
  <Grid Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
    <SplitView>
      <SplitView.Pane>
        <StackPanel HorizontalAlignment="Center"
                    VerticalAlignment="Center">
          <TextBlock Text="Pane"
                     TextWrapping="Wrap" />
          <Button Click="PaneButtonClick"
                  Content="Hide Pane" />
        </StackPanel>
      </SplitView.Pane>
      <Grid>
        <StackPanel HorizontalAlignment="Center"
                    VerticalAlignment="Center"
                    Orientation="Vertical">
          <TextBlock Text="Content Area" />
          <Button Click="ShowPaneButtonClick"
                  Content="Show Pane" />
        </StackPanel>
      </Grid>
    </SplitView>
  </Grid>
</Page>

DisplayMode Property on the UWP SplitView

The UWP SplitView has two properties that are worth exploring in a bit of detail and we’ll use these to control the behaviour, or should I say the layout, of the SplitView based on screen width. Let’s start with the easy one, which is the IsPaneOpen property. As you can imagine from the name, this property indicates whether the pane of the SplitView is currently open (i.e. displayed in full, rather than hidden or in compact mode), or not.

The second property worth looking at is the DisplayMode of the SplitView, and has the following four possible values:

  • Overlay – When the pane is visible it appears as an overlay across the content area. It doesn’t affect the size of the content area when it is shown/hidden.
  • Inline – When the pane is displayed it reduces the size of the content area by the width of the pane. As the pane is shown/hidden the width of the content area shrinks and grows accordingly.
  • CompactOverlay – Same as Overlay, except when the pane isn’t open, it still takes up space on the page equal to the CompactPaneLength property. Typically the compact view would show a list of icon buttons as a summary of the options available in the pane when it’s open.
  • CompactInline – Same as Inline, except when the pane isn’t open it still takes up space on the page equal to the CompactPaneLength property.

We’ll leave the use of the CompactOverlay and CompactInline options for the moment and focus on the other two options. The Overlay option is great for when the size of the application is narrow, for example on a mobile phone. The Inline option is better suited for when the application has sufficient width to allow the pane to be shown and there still to remain sufficient content area to be useful.

Using VisualState to Set DisplayMode

With this in mind, we’re going to use visual states to set the DisplayMode property based on the width of the application. For the purpose of this post we’re going to use a split point of 900, meaning that if the width of the application is greater than 900 the DisplayMode will be set to Inline. If it’s below 900 it’ll be set to Overlay.

To begin with, we’re going to set the default value of the DisplayMode to Compact by adding DisplayMode=”Compact” to the SplitView element. Next in Blend we’re going to add two visual states via the States window. In the States window, click the Add state group button and give the state group a name, SizeStateGroup.

Adding a Visual State Group

Next, click the Add state button twice to add two visual states and name them NarrowState and WideState. The actual names of the visual state group and the states are only for your benefit at this point, so you can name them according to what makes sense for you.

Adding a Visual State

Click on the WideState and you should see a red dot appear along side the state name. This indicates that Blend is in visual state editing mode. You should also see a red border appear around the main design area. Note that when you’re in visual state editing mode in Blend, any change you make via the tool windows (eg changing a property) will be tracked against the selected visual state.

Visual State Editing Mode

In visual state editing mode for the WideState, use the Properties window to change the DisplayMode to Inline. Next click the lightning icon button, Edit Adaptive Triggers, alongside the WideState visual state.

Adding an AdaptiveTrigger

In the Collection Editor: StateTriggers, set the MinWindowHeight to 0 and the MinWindowWidth to 900. This is adding a trigger which will return true when the width of the application exceeds 900. At this point the VisualStateManager will automatically switch to the WideState, without you having to explicitly run any code. Repeat the process of setting an adaptive trigger but this time for the NarrowState and set both MinWindowHeight and MinWindowWidth to 0.

The final XAML:

<Page x:Class="UwpSplitViewSample.MainPage"
      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
      xmlns:local="using:UwpSplitViewSample"
      xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
      mc:Ignorable="d">

  <Grid Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
    <SplitView x:Name="splitView"
               DisplayMode="Overlay">
      <SplitView.Pane>
        <StackPanel HorizontalAlignment="Center"
                    VerticalAlignment="Center">
          <TextBlock Text="Pane"
                     TextWrapping="Wrap" />
          <Button Click="PaneButtonClick"
                  Content="Hide Pane" />
        </StackPanel>
      </SplitView.Pane>
      <Grid>
        <StackPanel HorizontalAlignment="Center"
                    VerticalAlignment="Center"
                    Orientation="Vertical">
          <TextBlock Text="Content Area" />
          <Button Click="ShowPaneButtonClick"
                  Content="Show Pane" />
        </StackPanel>
      </Grid>
    </SplitView>
    <VisualStateManager.VisualStateGroups>
      <VisualStateGroup x:Name="SizeStateGroup">

        <VisualState x:Name="WideState">
          <VisualState.StateTriggers>
            <AdaptiveTrigger MinWindowHeight="0"
                             MinWindowWidth="900" />
          </VisualState.StateTriggers>
          <VisualState.Setters>
            <Setter Target="splitView.(SplitView.DisplayMode)" Value="Inline" />
          </VisualState.Setters>
        </VisualState>
        <VisualState x:Name="NarrowState">
          <VisualState.StateTriggers>
            <AdaptiveTrigger MinWindowHeight="0"
                             MinWindowWidth="0" />
          </VisualState.StateTriggers>
        </VisualState>
      </VisualStateGroup>
    </VisualStateManager.VisualStateGroups>
  </Grid>
</Page>

Note: In UWP the order of the VisualState elements doesn’t matter as all the AdaptiveTriggers are evaluated and the best match is determined. For example if the application width is 1000, the conditions for the triggers for both NarrowState and WideState are met. However, the WideState is a better match since the width is > 900. For Uno (i.e. iOS, Android and WebAssembly), the order matters – the first trigger to match, wins. In the above XAML you’ll see the WideState before the NarrowState to make sure that if the application width is > 900, the WideState visual state is active.

Opening and Closing the UWP SplitView Pane

If you run the application at this point and adjust the width of the application the DisplayMode property will switch between Inline and Overlay. However, you won’t notice any change because we currently don’t have a way to open the pane. To do this we’ll add some code to the Click event handlers we created earlier, as follows:

private void PaneButtonClick(object sender, RoutedEventArgs e)
{
    splitView.IsPaneOpen = false;
}
private void ShowPaneButtonClick(object sender, RoutedEventArgs e)
{
    splitView.IsPaneOpen = true;
}

UWP SplitView In Action

With all the XAML and code in place, let’s see it in action on all various platforms.

UWP with Resizing Application
Opening the Pane on WASM
Auto-dismiss Flyout on Android

In this post we’ve covered off how easily you can build a responsive interface using Blend and the UWP SplitView. The fact that it then just works on iOS, Android and WebAssembly is a big bonus thanks to the Uno platform.

Tutorial: How to Create a XAML Templated Control

In this post we’re going to cover creating a custom control that uses a control template to define how it looks, aka a Templated Control. The principles of templated, or lookless, controls have been adopted by most of the XAML based technologies but for the purpose of this post we’re going to start by building … Continue reading “Tutorial: How to Create a XAML Templated Control”

In this post we’re going to cover creating a custom control that uses a control template to define how it looks, aka a Templated Control. The principles of templated, or lookless, controls have been adopted by most of the XAML based technologies but for the purpose of this post we’re going to start by building for Windows (ie UWP) and then we’re going to leverage Uno to deliver the same control across iOS, Android and even the web using Web Assembly (WASM).

Full source code available on GitHub

Disclaimer: The purpose of this post is to walk through the process of creating a Templated Control. To do this we’re going to create a multi-switch control (i.e. a switch that has multiple positions). However, I haven’t attempted to win any design awards with this control. In fact the entire point of a Templated Control is that it’s possible to restyle the control and add animation etc without changing the basic functionality of the control.

Getting Started – Uno Project Templates

To get started a bit of house keeping – let’s make sure we have our project setup so that we can build a Templated Control in its own library (so we can reuse it) and that we have a set of head projects where we can test out our control. Since we’re going to use Uno to take our control cross platform, we’ll use the Uno project templates to get us started.

We’ll start by creating a new project based on the Cross-Platform App (Uno Platform). If you don’t have the Uno project templates installed you can grab the Uno Platform Solution Templates Visual Studio extension from the marketplace.

Set some basic project information – in this case our head projects are just for the purpose of testing our Templated Control so we’ve named it XAMLControlSample.

Once you’ve completed creating the new project you should have a solution with four head projects (iOS, Android, UWP and WASM) as well as a shared project. The XAML for the MainPage is in the shared project, which is where we’ll be adding an instance of our Templated Control to test it out after we’ve created it.

Speaking of which, we need to create a library for our Templated Control to reside in. We’ll add another project, this time based on the Cross-Platform Library (Uno Platform) project template. If you’re not interested in taking your Templated Control cross platform (i.e. you’re just building for UWP) you can simply create a class library based on the Class Library (Universal Windows) project template. The big difference with the Uno template is that it creates a project that is setup with multi-targeting, meaning that it will create a library that will have an iOS, Android, Windows and WASM binaries.

We’ll give our class library a name, in this case MyCustomControls.

The next step is to create our Templated Control. Unfortunately due to the limited support for multi-targeting within Visual Studio, if you attempt to add a new item directly to the class library, you won’t see any of the Windows Universal item templates. Instead what we need to do is to create the Template Control in the UWP head project and move the relevant files across to the class library. Right-click on the UWP head project and select Add, New Item. In the Add New Item dialog, select the Templated Control item template and give the control a name, in this case MultiSwitchControl.

After adding the Templated Control you should see two files added to the UWP head project: Generic.xaml (in the Themes folder) and MultiSwitchControl.cs (you Templated Control). Note that there’s no XAML file for the Templated Control (i.e. there’s no MultiSwitchControl.xaml), which you would get if you were creating a UserControl. This is because the XAML that defines how the Templated Control looks is all contained in the Style and the associated ControlTemplate.

The final piece of setup is just to move these two files, including the Themes folder, into the class library. After moving the files, you should make sure that you update the namespace of your Templated Control to reflect the correct project. In my case I had to change the namespace from XAMLControlSample to MyCustomControls.

After moving the Templated Control to its correct location, let’s make sure that it can be consumed by each of our head projects:

  • Update NuGet packages, importantly the Uno packages
  • For each head project add a reference to the MyCustomControls project.
  • Build and run each head project to make sure no compile errors (Note for WASM use the “Start without Debugging” option to launch the browser)

Once we’ve confirmed that each platform works without our Templated Control, it’s time to add an instance to the MainPage. Update the MainPage code to the following:

<Page x:Class="XAMLControlSample.MainPage"
      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
      xmlns:ctrls="using:MyCustomControls">
  <Grid Background="{ThemeResource ApplicationPageBackgroundThemeBrush}">
    <StackPanel>
      <TextBlock Margin="20"
                 HorizontalAlignment="Center"
                 Text="XAML Templated Control"
                 FontSize="30" />
      <ctrls:MultiSwitchControl
                                Width="400"
                                Height="400"
                                Background="Blue" />
    </StackPanel>
  </Grid>
</Page>

Run each of the head projects and verify that the MultiSwitchControl appears as a blue square.

Breaking Down the Templated Control

In the previous section we walked through creating a very simple Templated Control and demonstrated that through the power of Uno the same control can be used across iOS, Android, Windows and Web. Let’s take a look at how the Templated Control works, before we move on to building out our multi-switch control.

DefaultStyleKey for Implicit Style Lookup

The MultiSwitchControl.cs code file contains very little code. In fact, the only code it contains by default is a parameterless constructor that sets the DefaultStyleKey property.

public MultiSwitchControl()
{
    this.DefaultStyleKey = typeof(MultiSwitchControl);
}

What’s not apparent here is that setting the DefaultStyleKey is critical to the loading of the control. When an instance of the MultiSwitchControl is created, unless the Style attribute has been set, the framework looks for a corresponding implicit style. An implicit style is one that doesn’t have an explicit Key defined. Instead, the Key for an implicit style is essentially the TargetType of the Style. For example in the Generic.xaml you’ll see that there is a Style defined with TargetType set to MultiSwitchControl.

<Style TargetType="local:MultiSwitchControl" >
    <Setter Property="Template">
        <Setter.Value>
            <ControlTemplate TargetType="local:MultiSwitchControl">
                <Border
                    Background="{TemplateBinding Background}"
                    BorderBrush="{TemplateBinding BorderBrush}"
                    BorderThickness="{TemplateBinding BorderThickness}">
                </Border>
            </ControlTemplate>
        </Setter.Value>
    </Setter>
</Style>

What’s important to note is that when the framework looks for the implicit Style, it doesn’t just assume that it should look for a Style with the TargetType matching that of the control. Instead it looks at the Type returned by the DefaultStyleKey property. Whilst this property is often just set to the Type of the control, there are cases where this isn’t the case.

Making your Implicit Style Explicit

One thing that annoys me about the item template that is used to generate the Templated Control is that it only defines an implicit Style for the control. The weakness of this is that it means that any developer wanting to override the Style has to copy the entire Style into their application. A better alternative is to make your Style explicit by giving it a Key, thus making it possible for other developers to inherit from your Style using the BasedOn attribute.

Of course, if you make your Style explicit, your Templated Control will no longer be able to find the Style without you explicitly referencing it. This is simple to overcome by defining an implicit style that inherits from your explicit Style.

If this all sounds a little complex, check out the amended Styles for the MultiSwitchControl below (there’s no code changes required to the MultiSwitchControl itself since it still relies on the implicit Style).

<Style x:Key="MultiSwitchControlDefaultStyle"
     TargetType="local:MultiSwitchControl">
<Setter Property="Template">
  <Setter.Value>
    <ControlTemplate TargetType="local:MultiSwitchControl">
      <Border Background="{TemplateBinding Background}"
              BorderBrush="{TemplateBinding BorderBrush}"
              BorderThickness="{TemplateBinding BorderThickness}" />
    </ControlTemplate>
  </Setter.Value>
</Setter>
</Style>
<Style TargetType="local:MultiSwitchControl"
     BasedOn="{StaticResource MultiSwitchControlDefaultStyle}" />

Designing the Template Control

At this point we have a lot of the infrastructure in place so we can get on with actually building our Templated Control. In this case we’re building a four-way switch control. It actually has five states: Off (Center), Up, Right, Down, Left, and as mentioned earlier we’re going to put minimal effort into the default design/layout of the control. We’ll show at the end of the process how easy it is for a developer consuming the control to override the Style and provide their own design without having to re-code the operation of the control (i.e. a true lookless control).

Simple Box Layout for the Template Control

To keep things simple the layout for the multi-switch that we’ll add to the MultiSwitchControlDefaultStyle will be a cross based on a 5×5 grid. There will be a box defined in the middle of the top row (Up), the center of the fifth column (Right), the middle of the bottom row (Down), the center of the first column (Left) and at the intersection of the third row and third column (Off). We’ve used a 5×5 layout to give a bit of spacing between the boxes, as you can see from the following image.

The updates Style defines each box using a Grid. At this stage a Border element would have sufficed. However, as you’ll see in the next step we’ll be nesting a couple of elements in the box to provide the visual context for when the user moves the mouse over the box, presses or clicks on the box, and when the box is selected.

<Style x:Key="MultiSwitchControlDefaultStyle"
     TargetType="local:MultiSwitchControl">
<Setter Property="BorderBrush" Value="SteelBlue" />
<Setter Property="BorderThickness" Value="1" />
<Setter Property="Template">
  <Setter.Value>
    <ControlTemplate TargetType="local:MultiSwitchControl">
      <Grid>
        <Grid.ColumnDefinitions>
          <ColumnDefinition />
          <ColumnDefinition />
          <ColumnDefinition />
          <ColumnDefinition />
          <ColumnDefinition />
        </Grid.ColumnDefinitions>
        <Grid.RowDefinitions>
          <RowDefinition />
          <RowDefinition />
          <RowDefinition />
          <RowDefinition />
          <RowDefinition />
        </Grid.RowDefinitions>
        <Grid x:Name="PART_Off"
              Grid.Row="2"
              Grid.Column="2"
              Background="Transparent"
              BorderBrush="{TemplateBinding BorderBrush}"
              BorderThickness="{TemplateBinding BorderThickness}" />
        <Grid x:Name="PART_Up"
              Grid.Row="0"
              Grid.Column="2"
              Background="Transparent"
              BorderBrush="{TemplateBinding BorderBrush}"
              BorderThickness="{TemplateBinding BorderThickness}" />
        <Grid x:Name="PART_Right"
              Grid.Row="2"
              Grid.Column="4"
              Background="Transparent"
              BorderBrush="{TemplateBinding BorderBrush}"
              BorderThickness="{TemplateBinding BorderThickness}" />
        <Grid x:Name="PART_Down"
              Grid.Row="4"
              Grid.Column="2"
              Background="Transparent"
              BorderBrush="{TemplateBinding BorderBrush}"
              BorderThickness="{TemplateBinding BorderThickness}" />
        <Grid x:Name="PART_Left"
              Grid.Row="2"
              Grid.Column="0"
              Background="Transparent"
              BorderBrush="{TemplateBinding BorderBrush}"
              BorderThickness="{TemplateBinding BorderThickness}" />
      </Grid>
    </ControlTemplate>
  </Setter.Value>
</Setter>
</Style>

Note that in most cases where there is repeated XAML (for example setting the properties of Background, BorderBrush and BorderThickness) it pays to extract these into a Style that can simply be applied to all elements. However, in practice this both adds to the overhead of loading the control and you immediately run into limitations on the TemplateBinding markup extension. Attempting to extract these elements to a Style will result in a runtime exception that doesn’t seem to have a clear work around.

The next thing to note about the Style is that we’ve added a Setter for both BorderBrush and BorderThickness. The Setters define the default values for these properties, meaning that if the developer doesn’t explicitly set them on their instance of the MultiSwitchControl they’ll still have a value. If we didn’t do this, the default appearance of the MultiSwitchControl wouldn’t show the boxes since there would be no brush, and thickness would be 0.

The last thing to note about the Style is that each of the Grid elements have a Name attribute. In each case the value has the prefix “PART_” followed by the corresponding switch state eg PART_Off. This prefix was a convention adopted by WPF but subsequently dropped for Silverlight (see this post for some commentary on this topic), Windows Phone, UWP etc. Whilst you don’t have to adopt this prefix (you’ll see why in a minute) I still find it quite a clean way to identify parts of the Style that have to be there in order for the control to function correctly.

Visual States for the Templated Control

As mentioned earlier we want our Templated Control to be able to provide contextual feedback to the user. There are three things that we want to be able to do:

  • Indicate when the user moves the mouse (UWP & WASM) over a box
  • Indicate when the user clicks, presses, touches into a box
  • Indicate when the user has selected a box

The first two of these we’ll pair together as they can represent the current state of the input device (aka pointer). This will be our CommonStates VisualStateGroup, to be consistent with other Windows controls, and will contain the following Visual States:

  • Normal – pointer isn’t over any element or pressed down on any element
  • PointerOverXXX – pointer has entered the area of element XXX
  • PressedXXX – pointer has been pressed down on element XXX

Element XXX will be one of the Grid elements named in our Style, so our states will be PointerOverOff and PressedOff for the PART_Off Grid.

To track which box is currently selected we’ll create a second VisualStateGroup called SelectionStates, which will include Visual States with the naming convention SelectionXXX. So for the PART_Off Grid there will be a corresponding VisualState called SelectionOff. Additionally there will be one extra VisualState, SelectionNone, which represents the default state where no box has focus.

You might be asking at this point – why the need for two VisualStateGroups? or why not three? The answer to this is that VisualStateGroups should define mutually exclusive VisualStates; and that VisualStates from one group should not set the same properties as VisualStates from a different group. If we look at the scenarios above it’s very clear that we’d want to be able to specify which box is currently selected whilst being able to highlight a different box that the user may have moused over. What’s not immediately clear is why we’ve combined the PointerOver and the Pressed states into the one group. The reality is that we could have separated these into a third group. However, in this case we’re going to keep the implementation simple by assuming that the state of the pointer will either be PointerOver or Pressed and not both at the same time.

I mentioned earlier that each of the Grids we created for the different switch states were going to contain multiple elements. In fact we’re going to add three Border elements to each, with the resulting Grids all being similar to the following Part_Off Grid, where the element names have the switch state as their prefix eg OffPointerOver, OffPressed, OffSelection.

<Grid x:Name="PART_Off"
      Grid.Row="2"
      Grid.Column="2"
      Background="Transparent"
      BorderBrush="{TemplateBinding BorderBrush}"
      BorderThickness="{TemplateBinding BorderThickness}">
  <Border x:Name="OffPointerOver"
          Background="{TemplateBinding Background}"
          Visibility="Collapsed" />
  <Border x:Name="OffPressed"
          Opacity="{TemplateBinding PressedOpacity}"
          Background="{TemplateBinding Foreground}"
          Visibility="Collapsed" />
  <Border x:Name="OffSelection"
          Background="{TemplateBinding Foreground}"
          Visibility="Collapsed" />
</Grid>

Each Border has its Visibility property set to Collapsed. The OffPointerOver Border will be set to Visible when a Pointer enters the region of PART_Off. The OffPressed will be set to Visible when a Pointer is pressed inside the PART_Off. Lastly, the OffSelection will be set to Visible when the PART_Off is selected (i.e. the state of the switch is set to Off). All this of course has to be done with the corresponding visual states, as follows:

<VisualStateManager.VisualStateGroups>
  <VisualStateGroup x:Name="CommonStates">
    <VisualState x:Name="Normal" />
    <VisualState x:Name="PointerOverOff">
      <VisualState.Setters>
        <Setter Target="OffPointerOver.Visibility" Value="Visible" />
      </VisualState.Setters>
    </VisualState>
    ...
    <VisualState x:Name="PressedOff">
      <VisualState.Setters>
        <Setter Target="OffPressed.Visibility" Value="Visible" />
      </VisualState.Setters>
    </VisualState>
    ...
  </VisualStateGroup>
  <VisualStateGroup x:Name="SelectionStates">
    <VisualState x:Name="SelectionNone" />
    <VisualState x:Name="SelectionOff">
      <VisualState.Setters>
        <Setter Target="OffSelection.Visibility" Value="Visible" />
      </VisualState.Setters>
    </VisualState>
    ...
  </VisualStateGroup>
</VisualStateManager.VisualStateGroups>

The visual states for the other parts are all similar, just with different names in the Target of the Setter.

Building the Functionality of the Templated Control

So far we’ve focused on getting the basic layout of the Templated Control sorted. This has included specifying the different visual states that map to both user interaction (i.e. pointer over and pressed) as well as the switch states (i.e. selection). What’s missing is that actual functionality of the MultiSwitchControl which will trigger the changes in the visual states and track what the current switch state is.

Current Switch State

To track the current state of the switch I’m going to define an enum called SwitchState, which will include the values Off, Up, Right, Down and Left. For completion I’ve added a None state to represent an invalid or non-set state. I’ll then add a Value dependency property which will track the current state of the switch. when the Value does change, the ValuePropertyChanged method will be invoked, which subsequently calls the UpdateSwitchState that is responsible for calling GoToState on the VisualStateManager. The name of the new VisualState is specified by concatenating the prefix “Selection” with the current switch Value. For example if the current Value is SwitchState.Off, the visual state name would be SelectionOff.

public enum SwitchState
{
    None,
    Off,
    Up,
    Right,
    Down,
    Left
}

private const string SelectionStatePrefix = "Selection";

public static readonly DependencyProperty ValueProperty =
    DependencyProperty.Register(nameof(Value), typeof(SwitchState),
                                typeof(MultiSwitchControl),
                                new PropertyMetadata(SwitchState.None, ValuePropertyChanged));

public SwitchState Value
{
    get => (SwitchState)GetValue(ValueProperty);
    set => SetValue(ValueProperty, value);
}

private static void ValuePropertyChanged(DependencyObject dependencyObject, DependencyPropertyChangedEventArgs args)
{
    var switchControl = dependencyObject as MultiSwitchControl;
    switchControl?.UpdateSwitchState();
}

private void UpdateSwitchState()
{
    VisualStateManager.GoToState(this, SelectionStatePrefix + this.Value, true);
}

Pointer Events in the Templated Control

A lot of the visual state changes are conditional on intercepting pointer activity entering, exiting, pressing and release on the Templated Control. To attach the correct event handlers we need to override the OnApplyTemplate method – this method is called to apply the template to the control, afterwhich the various parts of the template are available to interact with.

private IDictionary<UIElement, (SwitchState state, bool isInside, bool isPressed)> Parts { get; } = new Dictionary<UIElement, (SwitchState state, bool isInside, bool isPressed)>();

protected override void OnApplyTemplate()
{
    base.OnApplyTemplate();

    var switchStates = new[] { SwitchState.Off, SwitchState.Up, SwitchState.Right, SwitchState.Down, SwitchState.Left };
    foreach (var s in switchStates)
    {
        SetupPart(s);
    }

    Value = SwitchState.Off;
}

private void SetupPart(SwitchState state)
{
    var partName = PartPrefix + state;
    var partOff = GetTemplateChild(partName) as UIElement;
    if (partOff == null) throw new NullReferenceException($"{partName} expected in control template");
    Parts[partOff] = (state: state, isInside: false, isPressed: false);
    partOff.PointerPressed += PartPointerPressed;
    partOff.PointerReleased += PartPointerReleased;
    partOff.PointerEntered += PartPointerEntered;
    partOff.PointerExited += PartPointerExited;
}

As the code above illustrates, the OnApplyTemplate method iterates through a list of switch states, invoking the SetupPart method, afterwhich it sets the default value of the switch to Off. The SetupPart method calls GetTemplateChild to retrieve the element generated by the corresponding template part. For example for the SwitchState.Off, the partName is “PART_Off”. Calling GetTemplateChild doesn’t retrieve the Grid from the ControlTemplate, it retrieves the Grid that was created as part of applying the ControlTemplate to the instance of the MultiSwitchControl.

The Parts dictionary is used to track the current state of each part of the MultiSwitchControl. More specifically it tracks whether a pointer is inside the part and whether the pointer has been pressed. As you’ll see in the next code snippet, these values are used to determine when different visual state changes are applied.

At this point we also wire up the event handlers for each of the pointer events. The expected flow is that a pointer will enter the part, it may then be pressed (which will capture the pointer), the pointer may then exit and/or release at some point in the future. If the pointer is released whilst still within the part, this will select the part and change the state of the MultiSwitchControl.

private void PartPointerEntered(object sender, PointerRoutedEventArgs e)
{
    var partElement = sender as UIElement;
    if (partElement == null)
    {
        return;
    }

    var part = Parts[partElement];
    Parts[partElement] = (part.state, true, part.isPressed);
    if (!part.isPressed)
    {
        VisualStateManager.GoToState(this, PointerOverStatePrefix + part.state, true);
    }
}

private void PartPointerExited(object sender, PointerRoutedEventArgs e)
{
    var partElement = sender as UIElement;
    if (partElement == null)
    {
        return;
    }

    var part = Parts[partElement];
    Parts[partElement] = (part.state, false, part.isPressed);
    if (!part.isPressed)
    {
        VisualStateManager.GoToState(this, NormalState, true);
    }
}

private void PartPointerPressed(object sender, PointerRoutedEventArgs e)
{
    var partElement = sender as UIElement;
    if (partElement == null)
    {
        return;
    }

    var part = Parts[partElement];
    if (!part.isInside && !part.isPressed)
    {
        // Hack to deal with Android not firing events correctly
        //VisualStateManager.GoToState(this, "Selection" + part.state, true);
        Value = part.state;
        VisualStateManager.GoToState(this, NormalState, true);
        return;
    }
    Parts[partElement] = (part.state, part.isInside, true);
    VisualStateManager.GoToState(this, PressedStatePrefix + part.state, true);
    partElement.CapturePointer(e.Pointer);
}

private void PartPointerReleased(object sender, PointerRoutedEventArgs e)
{
    var partElement = sender as UIElement;
    if (partElement == null)
    {
        return;
    }

    partElement.ReleasePointerCaptures();
    var part = Parts[partElement];
    Parts[partElement] = (part.state, part.isInside, false);
    if (part.isInside)
    {
        Value = part.state;
    }
    VisualStateManager.GoToState(this, NormalState, true);
}

What’s a TemplatePart?

Earlier in this post I mentioned that WPF had a pseudo standard for the naming of parts of the template that needed to exist. The more precise name for these elements are template parts and the reason that the naming convention is no longer widely adopted is that there is a more prescriptive way to communicate to developers the required parts of a control.

The TemplatePartAttribute should be used to define the name and, if necessary, the type of the content template that need to exist in order for the control to operate correctly. In the case of the MultiSwitchControl there are five template parts, so we add five instances of the TemplatePartAttribute to the MultiSwitchControl class.

[TemplatePart(Name = "PART_Off")]
[TemplatePart(Name = "PART_Up")]
[TemplatePart(Name = "PART_Right")]
[TemplatePart(Name = "PART_Down")]
[TemplatePart(Name = "PART_Left")]
public partial class MultiSwitchControl : Control

I’d love to stay that these attributes showed up in the visual designer in Visual Studio or Blend but the reality is that both designers are in a pretty messed up state right now, so I would count on getting any useful prompts. The best advice I’d give is that if you’re going to start messing with the template of a control, inspect the class for yourself and see what template parts are required.

Are We There Yet?

Yes, the good news is that we’ve got to a point where we have a functioning control. We’ve used all the power of UWP to separate the visuals (i.e. the ControlTemplate coupled with Visual States) from the underlying control functionality. The only real connection is via the named parts of the template.

The following GIFs illustrate the control running on Windows, Android and WASM:

Overriding the Style of a Templated Control

The last thing I wanted to illustrate is how it’s possible to adjust the layout and visual appearance of the switch control without impacting the way it works. In the App.xaml file in the shared project (i.e. not in the class library) I’ve copied across the Style for the MultiSwitchControl. I’ve subsequently modified the ControlTemplate as follows:

  • Instead of multiple rows, all the boxes are now placed in 1 row
  • Each box now has a rounded corner, effectively causing them to be circular in shape (this was admittedly a lazy way and I should really have made them ellipses).
<ControlTemplate TargetType="myCustomControls:MultiSwitchControl">
<Grid Background="Transparent"
      DataContext="{Binding RelativeSource={RelativeSource TemplatedParent}}">
  <Grid.ColumnDefinitions>
    <ColumnDefinition />
    <ColumnDefinition />
    <ColumnDefinition />
    <ColumnDefinition />
    <ColumnDefinition />
    <ColumnDefinition />
    <ColumnDefinition />
    <ColumnDefinition />
    <ColumnDefinition />
  </Grid.ColumnDefinitions>
  <Grid x:Name="PART_Left"
        Grid.Column="0"
        Background="Transparent"
        CornerRadius="30"
        BorderBrush="{TemplateBinding BorderBrush}"
        BorderThickness="{TemplateBinding BorderThickness}">
    <Border x:Name="PART_Left_PointerOver"
            Background="{TemplateBinding Background}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Left_Pressed"
            Opacity="{TemplateBinding PressedOpacity}"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Left_Selection"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
  </Grid>
  <Grid x:Name="PART_Down"
        Grid.Column="2"
        Background="Transparent"
        CornerRadius="30"
        BorderBrush="{TemplateBinding BorderBrush}"
        BorderThickness="{TemplateBinding BorderThickness}">
    <Border x:Name="PART_Down_PointerOver"
            Background="{TemplateBinding Background}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Down_Pressed"
            Opacity="{TemplateBinding PressedOpacity}"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Down_Selection"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
  </Grid>
  <Grid x:Name="PART_Off"
        Grid.Column="4"
        Background="Transparent"
        CornerRadius="30"
        BorderBrush="{TemplateBinding BorderBrush}"
        BorderThickness="{TemplateBinding BorderThickness}">
    <Border x:Name="PART_Off_PointerOver"
            Background="{TemplateBinding Background}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Off_Pressed"
            Opacity="{TemplateBinding PressedOpacity}"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Off_Selection"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
  </Grid>
  <Grid x:Name="PART_Up"
        Grid.Column="6"
        Background="Transparent"
        CornerRadius="30"
        BorderBrush="{TemplateBinding BorderBrush}"
        BorderThickness="{TemplateBinding BorderThickness}">
    <Border x:Name="PART_Up_PointerOver"
            Background="{TemplateBinding Background}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Up_Pressed"
            Opacity="{TemplateBinding PressedOpacity}"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Up_Selection"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
  </Grid>
  <Grid x:Name="PART_Right"
        Grid.Column="8"
        Background="Transparent"
        CornerRadius="30"
        BorderBrush="{TemplateBinding BorderBrush}"
        BorderThickness="{TemplateBinding BorderThickness}">
    <Border x:Name="PART_Right_PointerOver"
            Background="{TemplateBinding Background}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Right_Pressed"
            Opacity="{TemplateBinding PressedOpacity}"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
    <Border x:Name="PART_Right_Selection"
            Background="{TemplateBinding Foreground}"
            Visibility="Collapsed" />
  </Grid>
  <VisualStateManager.VisualStateGroups>
    ...
  </VisualStateManager.VisualStateGroups>
</Grid>
</ControlTemplate>

The only other change I needed to make was in MainPage I needed to change the instance of the MultiSwitchControl to reference the Style that I’d added. Now when I run my sample application I can see that the MultiSwitchControl looks dramatically different, and yet still functions the same way.

Wrapping up the Templated Control

As you’ve hopefully seen in this post there’s huge potential with a Templated Control to build a component that can be heavily reused and more importantly restyled. The point of Templated Controls, or lookless controls, is that the restyling shouldn’t change the core functionality.

What excites me about the Uno platform is that this stuff just works. The entire Templated Control I’ve walked through works on Android, iOS, Windows and WASM – what other technology allows you to do that, with the same ability to retemplate a control.

Don’t forget the full source code is available on GitHub

Deploying Uno Wasm using Blob Storage

Deploying Uno Wasm using Blob Storage

Earlier today I posted about deploying Uno on Wasm to an Azure App Service (to which the Uno team replied on Twitter with an updated web.config). I was thinking a bit more about how I would deploy a real Uno Wasm app and I realised that of course, there’s no server side logic, so I could just go host it off Blob Storage.

I ran up the Azure Storage Explorer and created a new container within an existing Blob Storage account


As I’m going to be serving up content directly from Blob Storage I need to make sure that I enable public read access on the individual blobs (the default is that there’s no public read access on the container or blobs). Right-click on the container and select Set Public Access Level


Set access to Public read access for blobs only


Now you can simply copy the Uno Wasm application into the container by dragging the files from File Explorer into the right pane of the Azure Storage Explorer. I found that the best folder to copy is the folder that Visual Studio uses to deploy files when you do a Publish. For my project this is found at FirstUnoProject.WasmobjReleasenetstandard2.0PubTmpOutFirstUnoProject.WasmdistbinReleasenetstandard2.0dist.

And that’s it – now I can run my Uno Wasm application by clicking the Copy URL from the tool bar and then switching to my browser and launching the corresponding URL.


The Uno Wasm application runs without any further configuration required.


Publishing Uno WebAssembly (Wasm) to Azure App Service

Publishing Uno WebAssembly (Wasm) to Azure App Service

I figured that since I had Uno working in WebAssembly locally on my machine that I’d try publishing it out to an Azure App Service. I mean, how hard could it be since Visual Studio recognises that the Wasm project is a web project (nice job there team Uno!) and even gives me the option to Publish.


Stepping through the publish wizard I decided to create a new Azure App Service


I made use of an existing Resource Group and App Service Plan that I had lying around.


After hitting Create and publish Visual Studio went off thinking for what seemed like a long time with nothing happening. I knew it was probably busy packaging and deploying but I didn’t see anything appear in the Output window…… not surprisingly because Visual Studio pushes all the logging for the publish operation to the Web Publish Activity window.


Once it was done Visual Studio launches a browser window displaying the root of the newly created App Service. Unfortunately, this is not my Uno project.


After investigating a little I realised that the publish operation was uploading the Wasm project to a sub folder of the wwwroot folder within the App Service (eg  wwwrootFirstUnoProject.WasmbinReleasenetstandard2.0distindex.html). I validated this by using the Advanced Tools from the Azure portal.


From the Advanced Tools, select Files


Browsing the files you can locate the index.html that gets published with the Wasm project. This is the file that hosts the wasm


Unfortunately just adding the appropriate path to the index.html to the site url doesn’t seem to work (ie this doesn’t work: https://firstunoproject.azurewebsites.net/FirstUnoProject.Wasm/dist/bin/Release/netstandard2.0/dist/index.html). However, you can easily set up a new application to point to the dist folder. Go to Application Settings and under the section Virtual  applications and directories, create a new mapping. In this case I’ve mapped /uno to the sitewwwrootFirstUnoProject.WasmdistbinReleasenetstandard2.0dist folder (you can get the folder from the “path” shown in the Kudo – Files explorer) and I’ve made it an Application.


If you now attempt to go to the index.html page in your new mapped folder (eg https://firstunoproject.azurewebsites.net/uno/index.html) you’ll find that you’ll see the “Loading…” text that comes with the Uno project template but your application won’t load. If you spin up the Chrome debugging tool you’ll see that it’s not able to find the mono.wasm file with a 404 being raised. Don’t bother trying to work out whether the file exists or not because the issue is that whilst the file exists, the Azure App Service isn’t going to serve it because it’s not a known file type. Luckily there’s a simple solution. Add the following Web.config to your Wasm project and publish your application again.

<?xml version=”1.0″ encoding=”UTF-8″?>
<configuration>
   <system.webServer>
     <staticContent>
       <remove fileExtension=”.clr” />
       <remove fileExtension=”.dll” />
       <remove fileExtension=”.json” />
       <remove fileExtension=”.wasm” />
       <remove fileExtension=”.woff” />
       <remove fileExtension=”.woff2″ />
       <mimeMap fileExtension=”.dll” mimeType=”application/octet-stream” />
       <mimeMap fileExtension=”.clr” mimeType=”application/octet-stream” />
       <mimeMap fileExtension=”.json” mimeType=”application/json” />
       <mimeMap fileExtension=”.wasm” mimeType=”application/wasm” />
       <mimeMap fileExtension=”.woff” mimeType=”application/font-woff” />
       <mimeMap fileExtension=”.woff2″ mimeType=”application/font-woff” />
     </staticContent>
     <httpCompression>
       <dynamicTypes>
         <add mimeType=”application/octet-stream” enabled=”true” />
         <add mimeType=”application/wasm” enabled=”true” />
       </dynamicTypes>
     </httpCompression>
   </system.webServer>
</configuration>

Now you should be able to launch your Uno wasm-based application hosted in Azure App Service


Updated Uno Visual Studio Extension

Updated Uno Visual Studio Extension

I just noticed that the Uno Visual Studio Extension has been updated, so I figured I’d give it a go in Visual Studio 2019. After installing the extension I used the new startup dialog on Visual Studio to “Create a new project”. I searched Uno but Cross-Platform or any of the target platforms would show you the templates.


After selecting the Cross-Platform App (Uno Platform) template I had to enter a few details before hitting Create


Seconds later I had a brand new solution with five projects giving me the ability to target iOS, Android and Wasm all from the code I write in a UWP app.


Selecting the Wasm project I set it as the startup project and hit F5 to run. After a few minutes of building (the first build is slow as it downloads packages etc) it launched Chrome with my fancy Hello World project running.


Note: Small confession that I had to run the project twice because the first time failed without error. On second attempt it ran successfully. However, it’s been a bit hit and miss in terms of getting it to run. I added “<MonoRuntimeDebuggerEnabled>true</MonoRuntimeDebuggerEnabled>” to the csproj file and that seems to have got it to run more reliably.

Adding Content

I wanted to add some content to my page but figured I’d start off slow – how about a couple of labels and a button:

<Page
     x_Class=”FirstUnoProject.MainPage”







     mc_Ignorable=”d”>
   <Grid Background=”{ThemeResource ApplicationPageBackgroundThemeBrush}”>
     <StackPanel>
       <TextBlock Text=”Hello, world !” Margin=”20″ FontSize=”30″ />
       <TextBlock Text=”Hello, world !” Margin=”20″ FontSize=”30″ />
       <TextBlock Text=”Hello, world !” Margin=”20″ FontSize=”30″ />
       <Button Content=”Press Me!” Click=”IveBeenPressed” />
     </StackPanel>
   </Grid>
</Page>

and a bit of code behind:

public async void IveBeenPressed(object sender, RoutedEventArgs e)
{
     await new MessageDialog(“I’ve been Pressed!”, “Pressed”).ShowAsync();
}

Now tell me you don’t expect this to work on the web, right? Sure enough works a treat.


It’d be great if the message box had “Pressed” as the title instead of “localhost:5210 says” but I’m still mind blown that this still works?

One thing to be aware of is that I’ve had some mixed experiences with Wasm as the resoluts seem to vary depending on which combination of Uno packages are referenced. This is definitely a work in progress but I feel that this is probably in line with where WebAssembly support is at across the board.

Web Development with NO JavaScript; Is Uno the Future Web Platform?

Web Development with NO JavaScript; Is Uno the Future Web Platform?

This is probably stating the obvious but I’m a big advocate for rich client applications. With the recent advances in PWAs I’m looking down the barrel of having to concede to all those fellow developers that have jacked themselves up on as many JavaScript frameworks they can find and now charge through the roof because they’re one of only a handful who actually understand the difference between == and ===. I’m sure the time will come but for now, it may be that the Uno Platform can help me leverage my UWP skills in building apps for iOS, Android and the Web (via WebAssembly).

In my previous post I covered Getting Started with Platform Uno where I simply used the extension to create a new project and discussed running it on various platforms. One of the features of UWP that I really like is that ability to gracefully handle different screen sizes through the use of Visual States. So I figured I’d give states a go in my basic Uno app. Here’s the XAML (note there’s no code behind) for my MainPage:

<Page x_Class=”UnoGettingStarted.MainPage”







       mc_Ignorable=”d”>
     <Grid>
         <VisualStateManager.VisualStateGroups>
             <VisualStateGroup x_Name=”SizeGroup”>
                 <VisualState x_Name=”Small”>
                    <VisualState.StateTriggers>
                         <AdaptiveTrigger MinWindowWidth=”0″ />
                     </VisualState.StateTriggers>

                     <VisualState.Setters>
                         <Setter Target=”MainContent.Visibility”
                                 Value=”Collapsed” />
                     </VisualState.Setters>
                 </VisualState>
                 <VisualState x_Name=”Large”>
                    <VisualState.StateTriggers>
                         <AdaptiveTrigger MinWindowWidth=”1000″ />
                     </VisualState.StateTriggers>

                 </VisualState>
             </VisualStateGroup>
         </VisualStateManager.VisualStateGroups>
         <StackPanel VerticalAlignment=”Stretch”
                     x_Name=”MainContent”
                     HorizontalAlignment=”Stretch”>
             <TextBlock Text=”Hello, world !”
                        Margin=”20″
                        FontSize=”30″ />
             <Button Content=”Test”
                     Click=”TestClick” />
         </StackPanel>
     </Grid>
</Page>

This XAML shows two Visual States, “Small,” hides the MainContent StackPanel, and “Large” which has no setters, so is the default states of the page. I’ve added an AdaptiveTrigger to both states for clarity. The “Small” Visual State for window sizes from 0; The “Large” Visual State for window sizes over 1000.

Whilst this is a relatively simple example, when I build and run this, it not only works on UWP (expected) but also on Wasm. The image below shows the output – the red text has been added afterwards to indicate which Visual State the page is in.


Serious props to the Platform Uno team, this is awesome.

Getting Started with Platform Uno

Getting Started with Platform Uno

A while ago I posted on Building a TipCalc using Platform Uno and at the time there was quite a few steps to jump through to get a basic application running from scratch. In this post I’m going to cover off how incredibly easy it now is to get started with the Uno Platform. Before I get into the steps, I want to give some background on why after almost a year am I coming back to looking at Uno. For those who have been reading my blog or have worked with Built to Roam you’ll know that we specialise in building cross-platform applications, whether it be a mobile app spanning iOS and Android, a Windows app targeting desktop and Xbox, or an enterprise solution that’s available across web, mobile and desktop. With a deep heritage in the Microsoft ecosystem we have seen the emergence of technologies such as Xamarin.Forms – historically this was rudimentary framework for rapidly developing forms based applications, primarily for line of business solutions. We’ve also seen other frameworks emerge such as React Native, Flutter and of course PWAs. Each framework has its advantaged and disadvantages; each framework uses a unique set of tools, workflow and languages. The question we continually ask ourselves is which framework is going to provide the best value for our customers and that will allow us to build user interfaces that include high fidelity controls and rich animation.

We also evaluate frameworks based on the target platforms that they support, which is what has led me to this post. One of the amazing things about Xamarin.Forms is that it has provided support for the three main platforms, iOS, Android and Windows, as part of the core platform. In fact the tag line is currently “Native UIs for iOS, Android and Windows from a single, shared codebase”.


What’s mind blowing is if you look at the Other Platforms page you’ll see that there is also support for GTK, Mac, Tizen and WPF. Unfortunately, these other platforms do not get the same love as the core platforms, so don’t expect them to be kept up to date with the latest releases.

At this point you might be thinking, why stray from Xamarin.Forms? Well in recent times there has been a shift away from supporting UWP as a core component of Xamarin.Forms. When asked on Twitter about UWP support for Shell, David Ortinau’s response was just another nail in the coffin for UWP app developers who are already struggling an up hill battle to convince customers of the value proposition of building for Windows.


So this leads me to again revisit other frameworks but we find the situation isn’t much better:

  • React Native – iOS and Android only – There is a React Native for Windows but again, it’s not part of the core offering, so it will trail (perhaps not by much but the commit history indicates a difference between 1 day ago for the main Reach Native repo and 26 days ago on the Windows repo, for the most recent commit).
  • Flutter – iOS and Android only – There is work on desktop embedding and having Flutter work on the web, so perhaps we’ll see more support beyond Google I/O
  • PWAs – varying level of support on different platforms – Clearly Microsoft sees this as the path forward for some of their Office suite of apps but the lack of native UI I think is still a limitation of PWAs.

At this point I remembered that Uno provided an interesting take on cross platform development. I also remembered that they’ve been doing a lot of work to support WebAssembly, so perhaps this could be the perfect solution. In the simplest form, the Uno Platform is #uwpeverywhere (an initiative that I’ve long believed Microsoft should have championed, after all it’s called Universal for a reason, right?) but beyond that Uno is about being able to “Build native apps for Mobile and Web using XAML and C#”.


Let’s get cracking with building a Uno application and see how it pans out. If you’re on the Uno Platform homepage and wondering how to get started, don’t worry, you’re not alone – I was looking for a big “Get Started” button but instead I see links to sample apps and to the source code. If you find yourself across at the source code, you’re about to embark down the wrong path – you don’t need to grab their source code as everything is distributed via nuget! So where do you go? Well you need to find the Uno Documentation and then click the link to Getting Started – now we’re cooking with gas! Unfortunately most of this page is pretty useless until you come to want to debug your application on WebAssembly. Instead what you really want to do i install the Uno Visual Studio Extension and use that to create your application.

Getting Started

  • Install the Uno Visual Studio Extension
  • Open Visual Studio and select File, New, Project
  • Search for “cross platform” and select the Cross-Platform App (Uno Platform) template


  • Important: Update nuget package references – if you don’t do this, it’s unlikely that your application will run as a WebAssembly (check the “Include prerelease” to get the latest update for Wasm support)


  • For WebAssembly in the csproj file:
    • Add <DotNetCliToolReference Include=”Uno.Wasm.Bootstrap.Cli” Version=”1.0.0-dev.214″ /> into the same ItemGroup as the PackageReference for Uno.Wasm.Bootstrap
    • Add <MonoRuntimeDebuggerEnabled>true</MonoRuntimeDebuggerEnabled> to the initial PropertyGroup
    • Change the Project element to <Project Sdk=”Microsoft.NET.Sdk.Web”>
  • Build and run each platform – I’m showing UWP, Android and WebAssembly here but iOS works straight from the template too


So, now that we have a UWP application that runs on iOS, Android, Windows and Web, are we satisfied with this as a cross platform solution? I think I’m enjoying working in UWP again but it’ll take a bit more investigation to see if this is a viable solution or not.

———-

Contact Built to Roam for more information on building cross-platform applications

———-

Building a TipCalc using Platform Uno

Building a TipCalc using Platform Uno

Recently I’ve been playing around with Platform.Uno – I’ve long held the view that Microsoft’s Xamarin.Forms was a stop-gap in delivering a true cross-platform solution. Whilst Xamarin.Forms is a highly productive platform, it has some severe limitations, specifically around overriding the look and feel of the native controls. This is where Flutter has stolen a lot of mindshare, mainly because customers and companies looking to build apps, no longer look for apps that match the platform style. They’re much more focussed on strong brand presence and great user experience, meaning that a great Material app on iOS will get better reviews and usage than a mediocre app that uses the default iOS style. Platform Uno attempts to deliver on what I believe the Universal Windows Platform (UWP) should have been – taking UWP XAML across iOS, Android and Web Assembly.

Anyhow, here goes with building a TipCalc. I’ll start with the basic UWP application:

I’ll create a separate project for our ViewModel:

Running the UWP app at this point gives an operational tip calculator


So now, let’s add some Uno goodness. We’ll start by moving the MainPage.xaml into its own class library:

  • Add a new project based on the Class Library (.NET Standard) project template, TipCalc.UI
  • Remove class1.cs
  • Add reference to project TipCalc.Core
  • Move MainPage.xaml and MainPage.xaml.cs to the TipCalc.UI project
  • Change namespace from TipCalc.UWP to TipCalc.UI for both MainPage.xaml and MainPage.xaml.cs
  • Edit TipCalc.UI.csproj to allow it to multi-target (ie generate multiple dlls that target UWP, Droid, iOS etc) and make sure correct build action is set for MainPage.xaml
  • Add reference to Uno.UI nuget package (currently in prerelease).
  • Final TipCalc.UI.csproj should look similar to
  • <Project Sdk=”MSBuild.Sdk.Extras/1.5.4″>
       <PropertyGroup>
         <TargetFrameworks>xamarinios10;MonoAndroid80;uap10.0</TargetFrameworks>
       </PropertyGroup>


      <PropertyGroup Condition=” ‘$(TargetFramework)’ == ‘uap10.0’ “>
         <GenerateLibraryLayout>true</GenerateLibraryLayout>
       </PropertyGroup>


      <ItemGroup Condition=” ‘$(TargetFramework)’ == ‘uap10.0’ “>
         <PackageReference Include=”Microsoft.NETCore.UniversalWindowsPlatform” Version=”6.1.5″ />
       </ItemGroup>


      <ItemGroup>
         <PackageReference Include=”Uno.UI” Version=”1.31.0-dev.52″ />
       </ItemGroup>


      <ItemGroup>
         <Page Include=”MainPage.xaml”>
           <SubType>Designer</SubType>
           <Generator>MSBuild:Compile</Generator>
         </Page>
       </ItemGroup>


      <ItemGroup>
         <ProjectReference Include=”..TipCalc.CoreTipCalc.Core.csproj” />
       </ItemGroup>
    </Project>

  • Add Uno.UI nuget reference to TipCalc.Core. Resulting csproj should look similar to
  • <Project Sdk=”MSBuild.Sdk.Extras/1.5.4″>
       <PropertyGroup>
         <TargetFrameworks>xamarinios10;MonoAndroid80;uap10.0</TargetFrameworks>
       </PropertyGroup>


      <ItemGroup>
         <PackageReference Include=”Uno.UI” Version=”1.31.0-dev.52″ />
       </ItemGroup>
    </Project>

  • Add reference to TipCalc.UI to TipCalc.UWP

By all accounts at this point you’ve done a fair bit of lifting with out much to show for it. In fact, because of some absolute genius coding by Microsoft, if you run the UWP application at this point you’ll most likely see a System.AccessViolationException when attempting to navigate to MainPage


This seems to be an issue where you’re attempting to navigate to a page that’s defined in a separate assembly and there are no other XAML pages defined in the head (ie UWP) project. Simple solution is just to add a dummy page to the UWP project that you’ll never use…. but seriously Microsoft??? Oh, and this isn’t the first time this has been pointed out (see https://social.msdn.microsoft.com/Forums/windowsserver/en-US/4efa91ad-fa8f-45f0-9864-c2fd2b24477c/uwpc-accessviolationexception-when-navigating-froma-another-assembly?forum=wpdevelop which links to an old post http://danielvaughan.org/posts/uwp/2015/08/15/UWP-AccessViolationException-when-Navigating-to-a-Page-in-Another-Assembly/)

Right, so the question is – after all this effort, how are we any closer to having a cross platform application. Well, let’s spit out the Android build:

  • Add a new project based on the Android App (Xamarin) project template, TipCalc.Droid
  • Use the Blank App template
  • Uninstall any of the Xamarin.Android.Support nuget packages that are installed by default
  • Add reference to Uno.UI nuget package
  • Add reference to both TipCalc.UI and TipCalc.Core
  • Add a reference to Mono.Android.Export
  • Add App.xaml and App.xaml.cs from the TipCalc.UWP project to the TipCalc.Droid project As Link
  • Alter MainActivity to the following
  • [Activity(
         MainLauncher = true,
         ConfigurationChanges = ConfigChanges.Orientation | ConfigChanges.ScreenSize,
         WindowSoftInputMode = SoftInput.AdjustNothing | SoftInput.StateHidden
    )]
    public class MainActivity : Windows.UI.Xaml.ApplicationActivity
    {
    }

  • Add an Application class as follows
  • [global::Android.App.ApplicationAttribute(
         Label = “@string/app_name”,
         LargeHeap = true,
         HardwareAccelerated = true,
         Theme = “@style/AppTheme”
    )]
    public class Application : Windows.UI.Xaml.NativeApplication
    {
         public Application(IntPtr javaReference, JniHandleOwnership transfer)
             : base(new App(), javaReference, transfer)
         {
         }
    }

Now we’re good to go. Set the TipCalc.Droid to be the start up project and off we go. The app looks basically the same as it did on UWP


This took quite a bit of effort to get going but now that it’s there, you can imagine that productivity is going to be quite good. Next up I’ll add in the iOS project but I don’t envisage that, nor Web Assembly, being that hard from the samples I’ve seen to date.

Source code available at https://github.com/nickrandolph/UnoSamples
